Taco® 00R-SF6-1IFC 00 Stainless Steel Circulator with Integral Flow Check, 0 to 12.5 gpm Flow Rate, 115 V, 1 Phase
CBPN: 306831
MPN:00R-SF6-1IFC
Price:
$553.06 / EA
DESCRIPTION
Taco® 00R-SF6-1IFC, Circulator with Integral Flow Check, Stainless Steel, Series: 00, 0 to 12.5 gpm Flow Rate, 15 ft Maximum Head, 115 V, 0.79 A, 1 ph, 125 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 6-3/8 in H x 5-15/16 in W x 2-15/16 in D Dimensions
Taco® 00R-SF6-1IFC 00 Stainless Steel Circulator with Integral Flow Check, 0 to 12.5 gpm Flow Rate, 115 V, 1 Phase
CBPN: 306831
MPN:00R-SF6-1IFC
Price:
$553.06 / EA
DESCRIPTION
Taco® 00R-SF6-1IFC, Circulator with Integral Flow Check, Stainless Steel, Series: 00, 0 to 12.5 gpm Flow Rate, 15 ft Maximum Head, 115 V, 0.79 A, 1 ph, 125 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 6-3/8 in H x 5-15/16 in W x 2-15/16 in D Dimensions
Specifications
Brand: Taco®
Weight: 9 lbs
Bearing Type: Carbon
Impeller Type: Non-Metallic
Temperature Rating: 40 to 230 deg F
Flow Rate: 0 to 12.5 gpm
Voltage Rating: 115 V
Phase: 1
Amperage Rating: 0.79 A
Dimensions: 6-3/8 in H x 5-15/16 in W x 2-15/16 in D
Manufacturer Name: Taco
Maximum Head: 15 ft
Maximum Pressure: 125 psi
Motor Speed: 3250 rpm
Mounting Type: Flange
Series: 00
Type: Stainless Steel
Application: For Radiant Heating Systems
Warranty: 3 Years
Country of Origin: US
Standards and Approvals: NSF Certified | UL Listed
Item Features
- Cast iron or stainless steel construction, flanged
- Easy to service
- Easy to service
- Eliminates separate in-line flow check
- Flange Orientation
- Improves performance
- Led indicator light
- Maintenance free
- Mounting Positions
- Prevents gravity flow / reverse flow
- Quiet,efficient operations
- Reduces installed cos
- Reduces installed cost
- Self lubricating,no mechanical seal
- Simplifies piping
- Specifically designed for radiant heating applications
- Standard Optional OK if over 20 psi
- Unique replaceable catridge field services
