Taco® 0014-F1 14 Series High Velocity Cartridge Circulator, 32 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 115 VAC, 1 Phase
CBPN: 98763
MPN:0014-F1
Price:
$558.56 / EA
DESCRIPTION
Taco® 0014-F1, Cartridge Circulator, High Velocity, Series: 14 Series, 32 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 22 ft Maximum Head, 1/8 hp Power, 115 VAC, 1.45 A, 60 Hz Frequency, 1 ph, 150 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 5-3/8 in W x 7-1/4 in D x 6-1/2 in H Dimensions
Taco® high velocity series 0014 cartridge circulator is specifically designed for medium head/medium flow applications in large residential/light commercial systems. Typical applications include large BTUH boilers, primary/secondary loops, commercial water heaters and light commercial heating/cooling systems.
Taco® 0014-F1 14 Series High Velocity Cartridge Circulator, 32 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 115 VAC, 1 Phase
CBPN: 98763
MPN:0014-F1
Price:
$558.56 / EA
DESCRIPTION
Taco® 0014-F1, Cartridge Circulator, High Velocity, Series: 14 Series, 32 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 22 ft Maximum Head, 1/8 hp Power, 115 VAC, 1.45 A, 60 Hz Frequency, 1 ph, 150 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 5-3/8 in W x 7-1/4 in D x 6-1/2 in H Dimensions
Taco® high velocity series 0014 cartridge circulator is specifically designed for medium head/medium flow applications in large residential/light commercial systems. Typical applications include large BTUH boilers, primary/secondary loops, commercial water heaters and light commercial heating/cooling systems.
Specifications
Brand: Taco®
Weight: 12 lbs
Bearing Type: Carbon
Impeller Type: Non-Metallic
Temperature Rating: 40 to 230 deg F
Flow Rate: 32 gpm
Inlet Size: 1-1/2, 1, 3/4, 1-1/4 in
Voltage Rating: 115 V AC
Phase: 1
Amperage Rating: 1.45 A
Dimensions: 5-3/8 in W x 7-1/4 in D x 6-1/2 in H
Frequency Rating: 60 Hz
Manufacturer Name: Taco
Maximum Head: 22 ft
Maximum Pressure: 150 psi
Motor Speed: 3250 rpm
Mounting Type: Flange
Power Rating: 1/8 hp
Series: 14 Series
Type: High Velocity
Includes: Flange Gaskets
Application: For Radiant Heating Systems, Domestic Water Systems, Chilled Water Cooling, Zoning with Circulators, Hydro-Air Fan Coils and Hydronic Heating System
Warranty: 3 Years
Country of Origin: US
Standards and Approvals: cULus Listed | NSF 372 | UL-CUS
Item Features
- Exclusive anti-condensate baffle (ACB) with ambient air flow
- No mechanical seal
- Universal flange to flange dimensions
- For indoor use only
- Low-lead compliant
- Construction: cast Iron casing (volute), aluminum stator housing, stainless steel cartridge, non-metallic impeller, ceramic shaft, carbon bearings, EPDM O-ring and gaskets
- Impedance protected permanent split capacitor motor
- 3/4, 1, 1-1/4, 1-1/2 in flanged connection
- Direct drive - Low power consumption
- Protects motor windings against condensate buildup
- High Velocity performance,Compact design
- Quiet, efficient operation
- Self lubricating
- Unique replaceable cartridge design, Field serviceable
- Unmatched reliability, Maintenance free
