Taco® 005-SF2 00 Stainless Steel Cartridge Circulator, 0 to 19 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 115 V, 1 Phase
CBPN: 306784
MPN:005-SF2
Price:
$550.93 / ea
DESCRIPTION
Taco® 005-SF2, Cartridge Circulator, Stainless Steel, Series: 00, 0 to 19 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 0 to 9 ft Maximum Head, 1/35 hp Power, 115 V, 0.54 A, 60 Hz Frequency, 1 ph, 125 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 6-3/8 in H x 4-3/4 in W x 5-5/8 in D Dimensions
Taco® 005-SF2 00 Stainless Steel Cartridge Circulator, 0 to 19 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 115 V, 1 Phase
CBPN: 306784
MPN:005-SF2
Price:
$550.93 / ea
DESCRIPTION
Taco® 005-SF2, Cartridge Circulator, Stainless Steel, Series: 00, 0 to 19 gpm Flow Rate, 1-1/2, 1, 3/4, 1-1/4 in Inlet, 0 to 9 ft Maximum Head, 1/35 hp Power, 115 V, 0.54 A, 60 Hz Frequency, 1 ph, 125 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Flange Mounting, 40 to 230 deg F, Carbon Bearing, 6-3/8 in H x 4-3/4 in W x 5-5/8 in D Dimensions
Specifications
Brand: Taco®
Weight: 8 lbs
Bearing Type: Carbon
Impeller Type: Non-Metallic
Temperature Rating: 40 to 230 deg F
Flow Rate: 0 to 19 gpm
Inlet Size: 1-1/2, 1, 3/4, 1-1/4 in
Voltage Rating: 115 V
Phase: 1
Amperage Rating: 0.54 A
Dimensions: 6-3/8 in H x 4-3/4 in W x 5-5/8 in D
Frequency Rating: 60 Hz
Manufacturer Name: Taco
Maximum Head: 0 to 9 ft
Maximum Pressure: 125 psi
Motor Speed: 3250 rpm
Mounting Type: Flange
Power Rating: 1/35 hp
Series: 00
Type: Stainless Steel
Includes: Flange Gaskets
Application: For Radiant Heating Systems, Domestic Water Systems, Chilled Water Cooling, Zoning with Circulators, Hydro-Air Fan Coils and Hydronic Heating System
Warranty: 3 Years
Country of Origin: US
Standards and Approvals: UL-CUS
Item Features
- Cast Iron or Stainless Steel Construction
- Cast Iron or Stainless Steel Construction
- Direct Drive-Low Power Consumption
- No Mechanical Seal
- Quiet, Efficient Operation
- Self Lubricating
- Standard High Capacity Output-Compact Design
- Unique Replaceable Cartridge - Field Serviceable
- Unique Replaceable Cartridge Design-Field Serviceable
- Unmatched Reliability - Maintenance Free
- Unmatched Reliability-Maintenance Free
