Taco® 0012-F4, Cartridge Circulator Pump, Cast Iron, Series: 00, Model: 0012, 52 gpm Flow Rate, 14-1/2 ft Maximum Head, 1/8 hp Power, 115 V, 1.33 Amps, 60 Hz Frequency, 1 ph, 150 psi Maximum, 3250 rpm Motor, Non-Metallic Impeller, Standard 2-Bolt Flange Mounting, 40 to 230 deg F, Carbon Bearing, 5-1/2 in L x 8-1/2 in H Dimensions, Domestic

The High Velocity series Taco® 0012 cartridge circulator is designed for high flow/medium head applications in large residential/light commercial hydronic heating, Radiant heating and chilled water cooling systems. The unique ACB anti-condensate baffle with ambient air flow prevents the build up of condensate on the motor windings when pumping chilled water. Its unique field-serviceable cartridge contains all moving parts. Replacing the cartridge rebuilds the circulator. With no mechanical seal, the self-lubricating, maintenance free design provides unmatched reliability. Compact and lightweight, with excellent performance characteristics, the 0012 is ideal for high efficiency jobs where space is a premium. Available in cast iron or bronze construction.
