Spirax Sarco 1810261 BTD52L Thermodynamic Clean Steam Trap, 1/2 in Nominal, Tube End Style, 0 to 450 deg C, 10 bar g Pressure, 316L Stainless Steel
CBPN: 122856
MPN:1810261
Price:
$1112.93 / EA
DESCRIPTION
Spirax Sarco Thermodynamic Clean Steam Trap, Series: BTD52L, 1/2 in Nominal, Tube End Style, 123 mm Length, 10 bar g Pressure, 316L Stainless Steel, 0 to 450 deg C, 36 in W Dimensions
The BTD52L is manufactured from 316L stainless steel specifically for mains drainage applications in clean steam systems.
Spirax Sarco 1810261 BTD52L Thermodynamic Clean Steam Trap, 1/2 in Nominal, Tube End Style, 0 to 450 deg C, 10 bar g Pressure, 316L Stainless Steel
CBPN: 122856
MPN:1810261
Price:
$1112.93 / EA
DESCRIPTION
Spirax Sarco Thermodynamic Clean Steam Trap, Series: BTD52L, 1/2 in Nominal, Tube End Style, 123 mm Length, 10 bar g Pressure, 316L Stainless Steel, 0 to 450 deg C, 36 in W Dimensions
The BTD52L is manufactured from 316L stainless steel specifically for mains drainage applications in clean steam systems.
Specifications
Brand: Spirax Sarco
Weight: 1 lbs
Nominal Size: 1/2 in
End Style: Tube
Material: Stainless Steel
Max Operating Pressure: 145 psig
Max Allowable Pressure: 232 psig/up to 122 deg F
Max Allowable Temperature: 842 deg F/up to 116 psig
Dimensions: 36 in W
Length: 123 mm
Manufacturer Name: Spirax-Sarco Inc
Series: BTD52L
Application: For mains drainage applications in clean steam systems
Standards and Approvals: EN 10204 3.1 | European Pressure Equipment Directive 2014/68/EU
Item Features
- Reduce maintenance time
- Robust design
Spirax Sarco 1810261 Spare Parts
CBPN:
74586
MPN:
1810080
In Stock: 24
Price:
$149.00 / EA
