Spirax Sarco 0788290, KA 51 Direct Acting Temperature Regulator Valve, 1 in, FNPT End Style, 10 bar
CBPN: 37494
MPN:0788290
Price:
$1415.05 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Direct Acting, 1 in Nominal, NPT, 10 bar, Bronze Body, Stainless Steel Trim, 5.3 in L
Specifications
Brand: Spirax Sarco
Weight: 9.1 lbs
Nominal Size: 1 in
End Style: FNPT
Pressure Rating: 10 bar
Body Material: Bronze
Dimensions: 5.3 in L
Manufacturer Name: Spirax-Sarco Inc
Series: KB51
Trim Material: Stainless Steel
Type: Direct Acting
Application: Industrial/Commercial
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Class IV Shut-Off | BS 1400 LG2 Body
Item Features
- Maximum allowable temperature: 500 deg F at 0 to 152 psig
- 11.4 Cv
- 12.4 deg p-band
- Differential pressure: 150 psi
- 2-port
- Maximum allowable pressure: 362 psig at 248 deg F
- 5.6 mm stroke
- 2 in inlet center to top
- Horizontal installation
- Normally open, single seat, with a bronzpressure balancing bellow
