Spirax Sarco 0787990, KY 51 Reverse Acting Temperature Regulator Valve With Fixed Bleed, 2 in, FNPT End Style, 6.9 bar
CBPN: 154088
MPN:0787990
Price:
$2951.13 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Reverse Acting, 2 in Nominal, NPT, 6.9 bar, Bronze Body, Stainless Steel Trim, 7.1 in L
Spirax Sarco 0787990, KY 51 Reverse Acting Temperature Regulator Valve With Fixed Bleed, 2 in, FNPT End Style, 6.9 bar
CBPN: 154088
MPN:0787990
Price:
$2951.13 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Reverse Acting, 2 in Nominal, NPT, 6.9 bar, Bronze Body, Stainless Steel Trim, 7.1 in L
Specifications
Brand: Spirax Sarco
Weight: 23.2 lbs
Nominal Size: 2 in
End Style: FNPT
Pressure Rating: 6.9 bar
Body Material: Bronze
Dimensions: 7.1 in L
Manufacturer Name: Spirax-Sarco Inc
Series: KY51
Trim Material: Stainless Steel
Type: Reverse Acting
Application: Industrial/Commercial
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Class IV Shut-Off | BS 1400 LG2 Body
Item Features
- Maximum allowable temperature: 500 deg F at 0 to 152 psig
- 39.6 Cv
- 23.8 deg p-band
- Differential pressure: 100 psi
- 2-port
- Maximum allowable pressure: 362 psig at 248 deg F
- 9.5 mm stroke
- 6 in inlet center to top
- Horizontal installation
- Normally closed, opens with rising temperature, single seat
- The valve incorporates a pressure balancing bellows, which enables the valve to operate against higher differential pressures
