Spirax Sarco 0290296, LCV-4 Lift Check Valve, 1 in, Flanged End Style, Cast Steel Body
CBPN: 222313
MPN:0290296
Price:
$1164.8 / EA
DESCRIPTION
Spirax Sarco Lift Check Valve, 1 in Nominal, Flanged, 606 psig Operating, 14 to 572 deg F Operating, Media: Steam, 7-3/4 in Inlet to Outlet Length, 4 in Top to Inlet Center, Cast Steel Body
The LCV3, LCV4, LCV6 and LCV7 lift check valves are designed in accordance with EN 12516 and ASME B16.34 to prevent reverse flow in horizontal pipeline installations. The design of these valves allows them to be easily serviced without removing the valve from the pipeline.
Spirax Sarco 0290296, LCV-4 Lift Check Valve, 1 in, Flanged End Style, Cast Steel Body
CBPN: 222313
MPN:0290296
Price:
$1164.8 / EA
DESCRIPTION
Spirax Sarco Lift Check Valve, 1 in Nominal, Flanged, 606 psig Operating, 14 to 572 deg F Operating, Media: Steam, 7-3/4 in Inlet to Outlet Length, 4 in Top to Inlet Center, Cast Steel Body
The LCV3, LCV4, LCV6 and LCV7 lift check valves are designed in accordance with EN 12516 and ASME B16.34 to prevent reverse flow in horizontal pipeline installations. The design of these valves allows them to be easily serviced without removing the valve from the pipeline.
Specifications
Brand: Spirax Sarco
Weight: 15 lbs
Nominal Size: 1 in
End Style: ANSI 300 Flange
Body Material: Cast Steel
Inlet to Outlet Length: 7-3/4 in
Manufacturer Name: Spirax-Sarco Inc
Media: Steam
Pressure Rating: 606 psig Operating
Temperature Rating: 14 to 572 deg F Operating
Top to Inlet Center: 4 in
Standards and Approvals: ASME B16.34 | ASTM A216 WCB | EN 12266-1: 2003 Rate F | EN 12516/10204 3.1 | European Pressure Equipment Directive 97/23/EC
Item Features
- Effective minimal maintenance free solutions
- Preventing reverse flow in pipelines
- Compact design
- Horizontal installation
- Stainless steel internals
- 12.9 Cv
- Maximum allowable pressure: 741 psig at 100 deg F
- Maximum allowable/operating temperature: 572 deg F at 577 psig
- 752 deg F at 503 psig maximum allowable/operating temperature with high temperature bolting
- 606 psig maximum operating pressure for saturated steam service
- Maximum cold hydraulic test pressure: 1117 psig
- Stainless steel disc
- ANSI 300 flanged connection
