Spirax Sarco 0232691, S2 Separator, 1-1/2 in, NPT, 145 psig
CBPN:7619
MPN:0232691
Price:
$932.75 / EA
DESCRIPTION
Spirax Sarco Separator, 1-1/2 in Nominal, NPT, 145 psig, 363 deg F, Ductile Iron Body, 12 in L
Moisture Separators are used to improve the quality of steam or compressed air either within the distribution system or on the supply inlet to equipment. Removal of moisture is by a series of baffles on which the suspended water droplets impinge and fall out by gravity to the drain, which must be piped to a trap.
Spirax Sarco 0232691, S2 Separator, 1-1/2 in, NPT, 145 psig
CBPN:7619
MPN:0232691
Price:
$932.75 / EA
DESCRIPTION
Spirax Sarco Separator, 1-1/2 in Nominal, NPT, 145 psig, 363 deg F, Ductile Iron Body, 12 in L
Moisture Separators are used to improve the quality of steam or compressed air either within the distribution system or on the supply inlet to equipment. Removal of moisture is by a series of baffles on which the suspended water droplets impinge and fall out by gravity to the drain, which must be piped to a trap.
Specifications
Brand: Spirax Sarco
Weight: 21.5lbs
Body Material: Ductile Iron
End Style: NPT
Nominal Size: 1-1/2 in
Series: S2
Temperature Rating: 363 deg F
Pressure Rating: 145 psig
Dimensions: 12 in L
Manufacturer Name: Spirax-Sarco Inc
Domestic/Import: Domestic
Country of Origin: US
Item Features
- Maximum allowable pressure: 188 psig at 428 deg F and 232 psig at 0 to 248 deg F
- Maximum allowable temperature: 428 dge F at 0 to 188 psig
- Horizontal installation
