Spears® E1555-020 True Union 2000 Electric Actuated Ball Valve, 2 in Nominal, Thread End Style, PVC Body, PTFE/HDPE Seat, EPDM O-Ring, 115 VAC, Domestic
CBPN:262133
MPN:E1555-020
Price:
$816.33 / EA
DESCRIPTION
Spears® Ball Valve, Standard, Series: True Union 2000, 2 in Nominal, 115 VAC, Thread, 235 psi, 73 deg F, Media: Water, Electrical Actuator, 8-3/8 in Top to Inlet Center, PVC Body, PTFE/HDPE Seat/EPDM O-Ring, Domestic
The Electro Actuated Ball Valve provides high quality, basic on-off electrical actuation at an economical price, with voltage options and special "2-wire" control available. This prepackaged combination is constructed with an all plastic NEMA 4X enclosure directly mounted to a PVC or CPVC valve body for lighter weight and a low profile design for minimal space requirements. All Electro Series Ball Valves are pressure rated to 235 psi and suitable for vacuum service. Available in IPS sizes 1/2 to 2 in, with socket, threaded, or flanged ends and choice of EPDM or FKM O-ring seals.
Spears® E1555-020 True Union 2000 Electric Actuated Ball Valve, 2 in Nominal, Thread End Style, PVC Body, PTFE/HDPE Seat, EPDM O-Ring, 115 VAC, Domestic
CBPN:262133
MPN:E1555-020
Price:
$816.33 / EA
DESCRIPTION
Spears® Ball Valve, Standard, Series: True Union 2000, 2 in Nominal, 115 VAC, Thread, 235 psi, 73 deg F, Media: Water, Electrical Actuator, 8-3/8 in Top to Inlet Center, PVC Body, PTFE/HDPE Seat/EPDM O-Ring, Domestic
The Electro Actuated Ball Valve provides high quality, basic on-off electrical actuation at an economical price, with voltage options and special "2-wire" control available. This prepackaged combination is constructed with an all plastic NEMA 4X enclosure directly mounted to a PVC or CPVC valve body for lighter weight and a low profile design for minimal space requirements. All Electro Series Ball Valves are pressure rated to 235 psi and suitable for vacuum service. Available in IPS sizes 1/2 to 2 in, with socket, threaded, or flanged ends and choice of EPDM or FKM O-ring seals.
Specifications
Brand: Spears®
Weight: 6.17lbs
Actuator Type: Electrical
Body Material: PVC
End Style: Thread
Nominal Size: 2 in
Series: True Union 2000
Temperature Rating: 73 deg F
Type: Standard
Electrical Ratings: 115 VAC
Pressure Rating: 235 psi
Media: Water
Softgoods Material: PTFE/HDPE Seat/EPDM O-Ring
Manufacturer Name: Spears Manufacturing
Top to Inlet Center: 8-3/8 in
Domestic/Import: Domestic
Country of Origin: US
Item Features
- Blocked seal carrier
- High impact PP NEMA 4X enclosure, 316 stainless steel fasteners
- 2-Position with stem-mounted visual open/close indicator
- General purpose true union design, 1/4-turn shutoff, basic on-off operation
- Industrial grade true union design, 1/4-turn shutoff, basic on-off operation
- Suitable for oil-free air handling to 25 psi
- 25% duty cycle
