Spears® 852-025CSR 1-Piece Flange, 2-1/2 in Nominal, CPVC, SCH 80/XH, Special Reinforced FNPT Connection, 150 lb, 7 in OD, Domestic
CBPN: 236071
UPC:054211823484
MPN:852-025CSR
Price:
$158.35 / EA
DESCRIPTION
Spears® Flange, 1-Piece, 2-1/2 in Nominal, 7 in Outside Dia, 5-1/2 in Bolt Circle, Special Reinforced FNPT, 150 psi, 150 lb, SCH 80/XH, 73 deg F, CPVC, Gray, 2-1/8 in L, Domestic
Spears® 852-025CSR 1-Piece Flange, 2-1/2 in Nominal, CPVC, SCH 80/XH, Special Reinforced FNPT Connection, 150 lb, 7 in OD, Domestic
CBPN: 236071
MPN:852-025CSR
UPC:054211823484
Price:
$158.35 / EA
DESCRIPTION
Spears® Flange, 1-Piece, 2-1/2 in Nominal, 7 in Outside Dia, 5-1/2 in Bolt Circle, Special Reinforced FNPT, 150 psi, 150 lb, SCH 80/XH, 73 deg F, CPVC, Gray, 2-1/8 in L, Domestic
Specifications
Brand: Spears®
Weight: 1.69 lbs
Nominal Size: 2-1/2 in
Material: CPVC
Connection Type: Special Reinforced FNPT
Schedule Rating: SCH 80/XH
Bolt Circle Diameter: 5-1/2 in
Color: Gray
Dimensions: 2-1/8 in L
Manufacturer Name: Spears Manufacturing
Outside Diameter: 7 in
Pressure Rating: 150 psi
Temperature Rating: 73 deg F
Type: 1-Piece
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM F439 | ASTM F1498 | ANSI B16.5 | ASTM D1784 | NSF 61
