Powers™ HydroGuard® 6550055 LFSH1430 High/Low XP Master Tempering Valve, 1-1/4 x 1-1/2 in Nominal, NPT End Style, 125 psi Pressure, 127 gpm Flow Rate, Brass Body, Domestic
CBPN:187696
UPC:686408614690
MPN:6550055
Price:
$5988.56 / EA
Prop 65:
DESCRIPTION
Powers™ HydroGuard® XP Master Tempering Valve, High/Low, Series: LFSH1430, 1-1/4 x 1-1/2 in Nominal, NPT, 125 psi, 5 to 200 deg F, 127 gpm, Media: Water, Brass Body, Polished Chrome, 15-1/4 in L, Domestic
Single solution High/Low valves available in three sizes that temper water as high as 201 gpm and as low as 1 gpm. All valves are listed to ASSE 1017 and certified to CSA B125. Valves feature advanced paraffin actuation technology and a booster funnel design for dynamic response and superior low flow temperature control. The LFSH1430 line also features a single-seat design for virtual shut down in the event of cold-water failure, triple-duty check stops with screens, and a 5 deg F (3 deg C) approach temperature for low temperature hot water supply. Valves are available in Lead Free rough bronze and chrome plated finish.
Powers™ HydroGuard® 6550055 LFSH1430 High/Low XP Master Tempering Valve, 1-1/4 x 1-1/2 in Nominal, NPT End Style, 125 psi Pressure, 127 gpm Flow Rate, Brass Body, Domestic
CBPN:187696
MPN:6550055
UPC:686408614690
Price:
$5988.56 / EA
Prop 65:
DESCRIPTION
Powers™ HydroGuard® XP Master Tempering Valve, High/Low, Series: LFSH1430, 1-1/4 x 1-1/2 in Nominal, NPT, 125 psi, 5 to 200 deg F, 127 gpm, Media: Water, Brass Body, Polished Chrome, 15-1/4 in L, Domestic
Single solution High/Low valves available in three sizes that temper water as high as 201 gpm and as low as 1 gpm. All valves are listed to ASSE 1017 and certified to CSA B125. Valves feature advanced paraffin actuation technology and a booster funnel design for dynamic response and superior low flow temperature control. The LFSH1430 line also features a single-seat design for virtual shut down in the event of cold-water failure, triple-duty check stops with screens, and a 5 deg F (3 deg C) approach temperature for low temperature hot water supply. Valves are available in Lead Free rough bronze and chrome plated finish.
Specifications
Brand: Powers™
Body Material: Brass
End Style: NPT
Flow Rate: 127 gpm
Nominal Size: 1-1/4 x 1-1/2 in
Series: LFSH1430
Temperature Rating: 5 to 200 deg F
Type: High/Low
Finish: Polished Chrome
Pressure Rating: 125 psi
Dimensions: 15-1/4 in L
Media: Water
Manufacturer Name: Watts Water Technologies
Application: Commercial, Non-Health Hazard Applications
Warranty: 1 year Limited
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASSE 1017 | Advanced Thermal Activation | CSA B125 | PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
Item Features
- Advanced thermal actuator
- Mounts in any position
- Dirt and lime resistant poppet and seat design
- Rotatable union triple-duty checkstops
- Vandal-resistant, locking mechanism to secure temperature setting
- Virtual shutoff if supply pressure fails
- Factory tested
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- 90 to 160 deg F adjustment temperature
