Marsh J7654P Severe Service Liquid Filled Pressure Gauge, 2-1/2" Dial Size, 0 to 200 psi Range, 1/4 in MNPT Bottom Mount, Stainless Steel Case
CBPN: 18535
MPN:J7654P
Price:
$33.70 / EA
DESCRIPTION
Marsh Severe Service Liquid Filled Pressure Gauge, Series J, 2-1/2" Dial Size, 1/4 in MNPT Bottom Mount, 0 to 200 psi Range, Stainless Steel Case, Brass Internals, Polycarbonate Lens, Accuracy +/-3/2/3% (ASME Grade B)
Marsh Instruments Severe Service Liquid Filled Gauges are designed to perform in rugged and harsh environmental conditions, especially where pulsation or vibration is a problem. Liquid Filled Gauges offer a significant cushioning and dampening effect, reducing pointer flutter and lubricating the internals.
Marsh J7654P Severe Service Liquid Filled Pressure Gauge, 2-1/2" Dial Size, 0 to 200 psi Range, 1/4 in MNPT Bottom Mount, Stainless Steel Case
CBPN: 18535
MPN:J7654P
Price:
$33.70 / EA
DESCRIPTION
Marsh Severe Service Liquid Filled Pressure Gauge, Series J, 2-1/2" Dial Size, 1/4 in MNPT Bottom Mount, 0 to 200 psi Range, Stainless Steel Case, Brass Internals, Polycarbonate Lens, Accuracy +/-3/2/3% (ASME Grade B)
Marsh Instruments Severe Service Liquid Filled Gauges are designed to perform in rugged and harsh environmental conditions, especially where pulsation or vibration is a problem. Liquid Filled Gauges offer a significant cushioning and dampening effect, reducing pointer flutter and lubricating the internals.
Specifications
Brand: Marsh
Weight: 1 lbs
Pressure Range: 0 to 200 psi
Dial Diameter: 2-1/2 in
Connection Size: 1/4 in MNPT
Mounting Type: Bottom Connection
Accuracy: +/-3/2/3%
Case Material: Stainless Steel
Liquid Filled: Glycerine
Display Type: Dual Scale - psi & kPa
Manufacturer Name: Marsh
Series: J Series Severe Service
Type: Severe Service
Application: For applications in harsh environments, especially where pulsation or vibration is a problem.
Warranty: 1 Year
Standards and Approvals: ASME B40.100 | ASME Grade B
Item Features
- Liquid filled for dampening effect
- Weatherproof/hermetically sealed
- Heavy duty 1 piece socket design
- Dual scale - psi & kPa
