CRANE® L47-1/2XUF-3 Gate Valve, 3 in Nominal, Butt Weld End Style, 150 lb, Cast Steel Body, Handwheel Actuator
CBPN: 24411
MPN:L47-1/2XUF-3
Price:
$2033.25 / EA
DESCRIPTION
CRANE® Gate Valve, Series: 47-1/2, 3 in Nominal, Butt Weld End Style, 285 psi Pressure, 150 lb Pressure Class, -20 to 100 deg F, Handwheel Actuator, 11.12 in Inlet to Outlet Length, 19 in Top to Inlet Center, Cast Steel Body, 410 Stainless Steel Trim, Graphite Packing Softgoods, 9 in Diameter Hand Wheel
CRANE® cast steel gate valves offer the ultimate in dependable service for steam, air, gas, oil, oil vapor, and high pressure installations. All have straight-through ports to assure minimum turbulence, erosion, and resistance to flow. They are available in a wide variety of trims.
CRANE® L47-1/2XUF-3 Gate Valve, 3 in Nominal, Butt Weld End Style, 150 lb, Cast Steel Body, Handwheel Actuator
CBPN: 24411
MPN:L47-1/2XUF-3
Price:
$2033.25 / EA
DESCRIPTION
CRANE® Gate Valve, Series: 47-1/2, 3 in Nominal, Butt Weld End Style, 285 psi Pressure, 150 lb Pressure Class, -20 to 100 deg F, Handwheel Actuator, 11.12 in Inlet to Outlet Length, 19 in Top to Inlet Center, Cast Steel Body, 410 Stainless Steel Trim, Graphite Packing Softgoods, 9 in Diameter Hand Wheel
CRANE® cast steel gate valves offer the ultimate in dependable service for steam, air, gas, oil, oil vapor, and high pressure installations. All have straight-through ports to assure minimum turbulence, erosion, and resistance to flow. They are available in a wide variety of trims.
Specifications
Brand: CRANE®
Weight: 67 lbs
Nominal Size: 3 in
End Style: Butt Weld
Pressure Class: 150 lb
Body Material: Cast Steel
Softgoods Material: Graphite Packing
Actuator Type: Handwheel
Hand Wheel Diameter: 9 in
Inlet to Outlet Length: 11.12 in
Manufacturer Name: Crane ChemPharma Energy
Pressure Rating: 285 psi
Series: 47-1/2
Temperature Rating: -20 to 100 deg F
Top to Inlet Center: 19 in
Trim Material: 410 Stainless Steel
Standards and Approvals: ASME B16.34 Steel Valves | ASME B16.10 Face to Face or End to End | ASME B16.5 Flange Dimension | ASME B.16.25 Wedge End | API 600 Basic Design | API 598 Testing | ASTM A216 Grade WCB
Item Features
- Outside screw and yoke
- Flexible wedge disc
- All seat ring are seal welded as standard
- Quality process fully documented, material fully traceable
- CRANE® recommends the use of manual or powered gear assistance for size 8 in and larger
- F6/Hard faced nominal trim
- 13 Cr ASTM A217 (CA 215) CoCra seating surface
