Bonomi 9300-12 High Performance Direct Mount Wafer Style Butterfly Valve, 12 in Nominal, Stainless Steel Disc, 300 lb, 316 Stainless Steel Body, Bare Stem, Carbon-Filled PTFE Seat, Import
CBPN: 305601
MPN:9300-12
Price:
$6515.50 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
Prop 65:
DESCRIPTION
Bonomi North America Butterfly Valve, High Performance Direct Mount Wafer Style, Series: 9300, 12 in Nominal, 300 lb, Bare Stem, 3.62 in Inlet to Outlet Length, 316 Stainless Steel Body, Stainless Steel Disc, 17-4PH Stainless Steel (Stem)/316 Stainless Steel (Pin) Stem & Pin Material, Carbon-Filled PTFE Seat, Import
Bonomi 9300-12 High Performance Direct Mount Wafer Style Butterfly Valve, 12 in Nominal, Stainless Steel Disc, 300 lb, 316 Stainless Steel Body, Bare Stem, Carbon-Filled PTFE Seat, Import
CBPN: 305601
MPN:9300-12
Price:
$6515.50 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
Prop 65:
DESCRIPTION
Bonomi North America Butterfly Valve, High Performance Direct Mount Wafer Style, Series: 9300, 12 in Nominal, 300 lb, Bare Stem, 3.62 in Inlet to Outlet Length, 316 Stainless Steel Body, Stainless Steel Disc, 17-4PH Stainless Steel (Stem)/316 Stainless Steel (Pin) Stem & Pin Material, Carbon-Filled PTFE Seat, Import
Specifications
Brand: Bonomi North America
Weight: 123.46 lbs
Nominal Size: 12 in
Type: High Performance Direct Mount Wafer Style
Disc Material: Stainless Steel
Seat Material: Carbon-Filled PTFE
Actuator Type: Bare Stem
End Style: Wafer
Pressure Class: 300 lb
Inlet to Outlet Length: 3.62 in
Manufacturer Name: Bonomi North America
Series: 9300
Stem & Pin Material: 17-4PH Stainless Steel (Stem)/316 Stainless Steel (Pin)
Warranty: 1 Year
Domestic/Import: Import
Country of Origin: CN
Standards and Approvals: ANSI Specified | ASTM A351 Grade CF8M Body/Disc | CSA Approved
Item Features
- ISO 5211 direct mounting pad/square stem
- Compact design, easy access to packing
- Replaceable seat design
- Multiple V-ring stem packing
- Reliable and consistent torques
- Carbon filled PTFE seat
- FKM O-ring
- Manually operated
