Apollo™ 8910324A 89-100 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Standard Port, Graphite/MPTFE/RPTFE Softgoods, Domestic
CBPN: 160704
UPC:670750162930
MPN:89-103-24A
Price:
$73.58 / EA
Prop 65:
DESCRIPTION
Apollo™ 8910324A, Ball Valve, 2-Piece, Series: 89-100, 1/2 in Nominal, FNPT End Style, 2000 psi CWP Pressure, Standard Port, 2-1/2 in Orifice, Lever Operated Actuator, 2.23 in Inlet to Outlet Length, 1.79 in Top to Inlet Center, Carbon Steel/RPTFE Trim, Graphite/MPTFE/RPTFE Softgoods, Domestic
Apollo™ 8910324A 89-100 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Standard Port, Graphite/MPTFE/RPTFE Softgoods, Domestic
CBPN: 160704
MPN:89-103-24A
UPC:670750162930
Price:
$73.58 / EA
Prop 65:
DESCRIPTION
Apollo™ 8910324A, Ball Valve, 2-Piece, Series: 89-100, 1/2 in Nominal, FNPT End Style, 2000 psi CWP Pressure, Standard Port, 2-1/2 in Orifice, Lever Operated Actuator, 2.23 in Inlet to Outlet Length, 1.79 in Top to Inlet Center, Carbon Steel/RPTFE Trim, Graphite/MPTFE/RPTFE Softgoods, Domestic
Specifications
Brand: Apollo™
Weight: 0.63 lbs
Nominal Size: 1/2 in
End Style: FNPT
Pressure Rating: 2000 psi CWP
Body Material: Carbon Steel
Port Type: Standard
Softgoods Material: Graphite/MPTFE/RPTFE
Actuator Type: Lever Operated
Ball Material: Carbon Steel
Inlet to Outlet Length: 2.23 in
Manufacturer Name: Apollo Conbraco
Orifice Size: 2-1/2 in
Series: 89-100
Top to Inlet Center: 1.79 in
Trim Material: Carbon Steel/RPTFE
Type: 2-Piece
Includes: Adjustable Packing Gland
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM A216 WCB Body | ASTM A08 Ball/Stem | MSS SP-110 | NACE MR0175/MR0103 | PROP65: Cancer and Reproductive Harm
Item Features
- 24 - RPTFE bearing
- Investment cast components
- Reinforced seat
- Mounting pad for easy actuator mounting
- Blow-out proof stem design
- Zinc phosphate corrosion protection
- Cold non-shock body rating
- 150 psi saturated steam
- Vacuum service to 29 in Hg, graphite packing
- Not always fire safe
