Apollo™ 16-203-06

Apollo™ 16-203-06 16 Series, 16-203 General Purpose Pressure Relief Valve, 3/4 x 1/2 in Nominal, Male x Female End Style, Cast Bronze Body, Domestic

CBPN:247000

UPC:670750500626

MPN:16-203-06

Price:
$28.00 / EA
Availability Information
Prop 65:

DESCRIPTION

Apollo™ Pressure Relief Valve, General Purpose, Series: 16 Series, 3/4 x 1/2 in Nominal, Male x Female, 120 deg F, Media: Water/Air/Oil/Non-Hazardous Liquids, Cast Bronze Body, Stainless Steel Trim, Silicon Softgoods, 2-1/2 in H, Domestic

Economical relief valves for general purpose non-code overpressure protection and bypass relief applications. Applications include liquid bypass or thermal expansion relief of well pumps, tanks, fire protection systems and all types of water or liquid piping systems. Not intended for steam service.

Apollo™ 16-203-06 16 Series, 16-203 General Purpose Pressure Relief Valve, 3/4 x 1/2 in Nominal, Male x Female End Style, Cast Bronze Body, Domestic

CBPN:247000

MPN:16-203-06

UPC:670750500626

Price:
$28.00 / EA
Availability Information

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ Pressure Relief Valve, General Purpose, Series: 16 Series, 3/4 x 1/2 in Nominal, Male x Female, 120 deg F, Media: Water/Air/Oil/Non-Hazardous Liquids, Cast Bronze Body, Stainless Steel Trim, Silicon Softgoods, 2-1/2 in H, Domestic

Economical relief valves for general purpose non-code overpressure protection and bypass relief applications. Applications include liquid bypass or thermal expansion relief of well pumps, tanks, fire protection systems and all types of water or liquid piping systems. Not intended for steam service.

Specifications

BrandApollo™
Body MaterialCast Bronze
Domestic/ImportDomestic
End StyleMNPT x FNPT
Nominal Size3/4 x 1/2 in
Pressure Rating175 psig
Series16 Series
Temperature Rating120 deg F
TypeGeneral Purpose
Dimensions2-1/2 in H
MediaWater/Air/Oil/Non-Hazardous Liquids
Set Pressure175 psig
Softgoods MaterialSilicon
Trim MaterialStainless Steel

Item Features

  • Standard pressure settings from 50 to 175 psi
  • Stainless steel springs
  • Silicon soft seat ensures seat tightness, extended service life
  • All valves are 100% factory tested
