WATTS® 0547125 FBV-3C 2-Piece Ball Valve, 1/4 in Nominal, FNPT End Style, Brass Body, Full Port, PTFE Softgoods, Import
CBPN:140960
UPC:098268340952
MPN:0547125
Price:
$37.00 / EA
DESCRIPTION
WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 1/4 in Nominal, FNPT End Style, 600 psi WOG Pressure, -40 to 400 deg F, Full Port, 1/2 in Orifice, Brass Ball, 1-3/4 in Inlet to Outlet Length, 1-13/16 in Top to Inlet Center, Brass Body, Brass Stem and PTFE Seat Trim, PTFE Softgoods, Import
This 1/4 in 2-piece full port brass ball valve, series FBV-3C, is used in commercial and industrial applications for a full range of liquids and gases. It features a bottom-loaded blow-out proof stem, virgin PTFE seat, thrust washer and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter and steel handle.
WATTS® 0547125 FBV-3C 2-Piece Ball Valve, 1/4 in Nominal, FNPT End Style, Brass Body, Full Port, PTFE Softgoods, Import
CBPN:140960
MPN:0547125
UPC:098268340952
Price:
$37.00 / EA
DESCRIPTION
WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 1/4 in Nominal, FNPT End Style, 600 psi WOG Pressure, -40 to 400 deg F, Full Port, 1/2 in Orifice, Brass Ball, 1-3/4 in Inlet to Outlet Length, 1-13/16 in Top to Inlet Center, Brass Body, Brass Stem and PTFE Seat Trim, PTFE Softgoods, Import
This 1/4 in 2-piece full port brass ball valve, series FBV-3C, is used in commercial and industrial applications for a full range of liquids and gases. It features a bottom-loaded blow-out proof stem, virgin PTFE seat, thrust washer and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter and steel handle.
Specifications
Brand: WATTS®
Body Material: Brass
End Style: FNPT
Nominal Size: 1/4 in
Series: FBV-3C
Temperature Rating: -40 to 400 deg F
Type: 2-Piece
Pressure Rating: 600 psi WOG
Orifice Size: 1/2 in
Port Type: Full
Softgoods Material: PTFE
Trim Material: Brass Stem and PTFE Seat
Ball Material: Brass
Inlet to Outlet Length: 1-3/4 in
Manufacturer Name: Watts Water Technologies
Top to Inlet Center: 1-13/16 in
Application: Open/Close Commercial and Industrial
Warranty: 1 year
Domestic/Import: Import
Country of Origin: CN
Standards and Approvals: ASME B16.33/B16.44 | cCSAus Certified | FM Approved | UL Listed
Item Features
- Trim and drain model with UL/FM approval
- Made of durable brass
- Fluorocarbon elastomer stem O-Ring prevents stem leaks
- Adjustable stem packing gland
- Bottom loaded, blow-out proof stem
- 150 psi steam working pressure
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- Chrome plated brass ball
- PTFE stem packing seal/thrust washer
