WATTS® 0547103 FBV-3C 2-Piece Ball Valve, 3/4 in Nominal, FNPT End Style, Forged Brass Body, Full Port, Fluorocarbon/Virgin PTFE Softgoods, Import
CBPN:106230
UPC:098268335996
MPN:0547103
Price:
$14.31 / EA
DESCRIPTION
WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 3/4 in Nominal, FNPT End Style, 600 psi Pressure, -40 to 400 deg F, Full Port, Media: Gas/Liquids, Chrome Plated Brass Ball, 2-5/16 in Inlet to Outlet Length, 2-1/4 in Top to Inlet Center, Forged Brass Body, Brass Stem and PTFE Seat Trim, Fluorocarbon/Virgin PTFE Softgoods, Import
Series FBV-3C, FBVS-3C 2-Piece, Full Port, Brass Ball Valves are used in commercial and industrial applications for a full range of liquids and gases. They feature a bottom-loaded blow-out proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter, and steel handle. Model FBV-3C has threaded end connections. Model FBV-3C-TH has tee handle with threaded connections. Model FBVS-3C has solder end connections. Model FBVS-3C-TH has tee handle with solder connections.
WATTS® 0547103 FBV-3C 2-Piece Ball Valve, 3/4 in Nominal, FNPT End Style, Forged Brass Body, Full Port, Fluorocarbon/Virgin PTFE Softgoods, Import
CBPN:106230
MPN:0547103
UPC:098268335996
Price:
$14.31 / EA
DESCRIPTION
WATTS® Ball Valve, 2-Piece, Series: FBV-3C, 3/4 in Nominal, FNPT End Style, 600 psi Pressure, -40 to 400 deg F, Full Port, Media: Gas/Liquids, Chrome Plated Brass Ball, 2-5/16 in Inlet to Outlet Length, 2-1/4 in Top to Inlet Center, Forged Brass Body, Brass Stem and PTFE Seat Trim, Fluorocarbon/Virgin PTFE Softgoods, Import
Series FBV-3C, FBVS-3C 2-Piece, Full Port, Brass Ball Valves are used in commercial and industrial applications for a full range of liquids and gases. They feature a bottom-loaded blow-out proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter, and steel handle. Model FBV-3C has threaded end connections. Model FBV-3C-TH has tee handle with threaded connections. Model FBVS-3C has solder end connections. Model FBVS-3C-TH has tee handle with solder connections.
Specifications
Brand: WATTS®
Body Material: Brass
End Style: FNPT
Nominal Size: 3/4 in
Series: FBV-3C
Temperature Rating: -40 to 400 deg F
Type: 2-Piece
Pressure Rating: 600 psi
Media: Gas/Liquids
Port Type: Full
Softgoods Material: Fluorocarbon/Virgin PTFE
Trim Material: Brass Stem and PTFE Seat
Ball Material: Chrome Plated Brass
Inlet to Outlet Length: 2-5/16 in
Manufacturer Name: Watts Water Technologies
Top to Inlet Center: 2-1/4 in
Application: Commercial and Industrial Applications
Warranty: 1 year Limited
Domestic/Import: Import
Country of Origin: CN
Standards and Approvals: ASME B16.33/B16.44 | CSA Certified | FM Approved | MSS-SP-110 Compliant | UL Listed
Item Features
- Made of durable brass
- Fluorocarbon elastomer stem O-Ring prevents stem leaks
- Adjustable stem packing gland nut
- Bottom loaded, blow-out proof stem
- Machined chrome plated brass ball
- Recommended for open/close applications
- 150 psi steam working pressure
- Fluorocarbon elastomer O-ring and virgin PTFE stem packing seal/thrust washer
