WATTS® 0450103
WATTS® 0450103
WATTS® 0450103

WATTS® 0450103 2-Piece Ball Valve, 3/4 in Nominal, NPT End Style, Forged Bronze Body, Full Port, Virgin PTFE/Fluorocarbon Elastomer Softgoods, Domestic

CBPN:191716

UPC:098268763379

MPN:0450103

Price:
$44.42 / EA
in stock: 10

DESCRIPTION

WATTS® Ball Valve, 2-Piece, 3/4 in Nominal, NPT, 600 psi, 0 to 400 deg F, Full Port, Media: Gas/Liquid, Chrome Plated Brass Ball, 2-1/4 in Inlet to Outlet Length, 2-1/4 in Top to Inlet Center, Forged Bronze Body, Brass Stem Trim, Virgin PTFE/Fluorocarbon Elastomer, Domestic

Series LFB6080G2, LFB6081G2 2-Piece, Full Port, Lead Free bronze Ball Valves are used in commercial and industrial applications for a full range of liquids and gasses. They feature a blow-out proof pressure full-port orifice which ensures minimal pressure drop. Model LFB6080G2 has threaded NPT end connections and Model LFB6081G2 has solder end connections. The Series FB6080G2 and LFB6081G2 features Lead Free construction to comply with Lead Free installation requirements.

WATTS® 0450103 2-Piece Ball Valve, 3/4 in Nominal, NPT End Style, Forged Bronze Body, Full Port, Virgin PTFE/Fluorocarbon Elastomer Softgoods, Domestic

CBPN:191716

MPN:0450103

UPC:098268763379

Price:
$44.42 / EA
in stock: 10

Watts logo

DESCRIPTION

WATTS® Ball Valve, 2-Piece, 3/4 in Nominal, NPT, 600 psi, 0 to 400 deg F, Full Port, Media: Gas/Liquid, Chrome Plated Brass Ball, 2-1/4 in Inlet to Outlet Length, 2-1/4 in Top to Inlet Center, Forged Bronze Body, Brass Stem Trim, Virgin PTFE/Fluorocarbon Elastomer, Domestic

Series LFB6080G2, LFB6081G2 2-Piece, Full Port, Lead Free bronze Ball Valves are used in commercial and industrial applications for a full range of liquids and gasses. They feature a blow-out proof pressure full-port orifice which ensures minimal pressure drop. Model LFB6080G2 has threaded NPT end connections and Model LFB6081G2 has solder end connections. The Series FB6080G2 and LFB6081G2 features Lead Free construction to comply with Lead Free installation requirements.

Specifications

BrandWATTS®
Body MaterialForged Bronze
Domestic/ImportDomestic
End StyleNPT
Nominal Size3/4 in
Pressure Rating600 psi
Temperature Rating0 to 400 deg F
Type2-Piece
MediaGas/Liquids
Port TypeFull
Softgoods MaterialVirgin PTFE/Fluorocarbon Elastomer
Trim MaterialBrass Stem
Ball MaterialChrome Plated Brass
Inlet to Outlet Length2-1/4 in
Top to Inlet Center2-1/4 in

Item Features

  • Lead free forged bronze body and adapter
  • After soldering, the packing nut may have to be tightened
  • The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
  • Virgin PTFE stem packing seal and fluorocarbon elastomer O-ring
  • Stainless steel ball and stem
  • Minimal pressure drop due to large ports
  • Blow-out proof, pressure retaining stem
  • White handle for easy Lead free identification
  • Dual stem seal
  • Reversible handle that provides flexibility when installing multiple ball valves in a series, where space is tight
  • Metal-to-metal adapter seal with high temperature thread sealant
  • Excessive heat can harm the seats
