Tylok® CBC-Lok® SS-8-DBHFP-8 DBHFP Double Ferrule Bulkhead Female Pipe Connector, 1/2 in, Tube x FNPT, 316 Stainless Steel, Domestic
CBPN: 139799
UPC:811731024568
MPN:SS-8-DBHFP-8
DESCRIPTION
Tylok® CBC-Lok® Bulkhead Female Pipe Connector, Double Ferrule, Series: DBHFP, Fitting/Connector Type: Connector, 1/2 in Nominal Size, Tube x FNPT, 1-1/16 in Hex, 2.62 in Length, 316 Stainless Steel, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Tylok® CBC-Lok® SS-8-DBHFP-8 DBHFP Double Ferrule Bulkhead Female Pipe Connector, 1/2 in, Tube x FNPT, 316 Stainless Steel, Domestic
CBPN: 139799
MPN:SS-8-DBHFP-8
UPC:811731024568
DESCRIPTION
Tylok® CBC-Lok® Bulkhead Female Pipe Connector, Double Ferrule, Series: DBHFP, Fitting/Connector Type: Connector, 1/2 in Nominal Size, Tube x FNPT, 1-1/16 in Hex, 2.62 in Length, 316 Stainless Steel, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Specifications
Item Features
- Double ferrule swaging action
- Total component interchangeability
- Heat code traceable
- ASTM material construction
- 1/2-14 NPT pipe thread
- 90 Rb hardness
- Interchanges with 810-71-8 and 8FBC8N
