Tylok® Ty-Flo® SS-6-6DD-6 Needle Valve, 3/8 in Nominal, CBC-Lok® Tube End Style, 10000 psi Pressure, 316 Stainless Steel Body
CBPN: 177386
UPC:811731026005
MPN:SS-6-6DD-6
Price:
$167.50 / EA
DESCRIPTION
Tylok® Ty-Flo® Needle Valve, 3/8 in Nominal, CBC-Lok® Tube, 10000 psi, -10 to 200 deg F, 3.08 in Inlet to Outlet Length, 2.13 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel Trim, FKM
Tylok® Ty-Flo® SS-6-6DD-6 Needle Valve, 3/8 in Nominal, CBC-Lok® Tube End Style, 10000 psi Pressure, 316 Stainless Steel Body
CBPN: 177386
MPN:SS-6-6DD-6
UPC:811731026005
Price:
$167.50 / EA
DESCRIPTION
Tylok® Ty-Flo® Needle Valve, 3/8 in Nominal, CBC-Lok® Tube, 10000 psi, -10 to 200 deg F, 3.08 in Inlet to Outlet Length, 2.13 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel Trim, FKM
Specifications
Brand: Tylok®
Weight: 0.52 lbs
Nominal Size: 3/8 in
End Style: CBC-Lok® Tube
Pressure Rating: 10000 psi
Body Material: 316 Stainless Steel
Inlet to Outlet Length: 3.08 in
Manufacturer Name: Tylok International
Softgoods Material: FKM
Temperature Rating: -10 to 200 deg F
Top to Inlet Center: 2.13 in
Trim Material: 316 Stainless Steel
Application: Fluid Control
Warranty: 1 year Limited
Country of Origin: US
Item Features
- CBC-Lok® double ferrule tube ends are completely interchangeable with Swagelok® and Parker A-Lok® tube ends
- FKM stem O-ring
