Tylok® SS-4-DMC-4

Tylok® CBC-Lok® SS-4-DMC-4 DMC Double Ferrule Male Connector, 1/4 in, Tube x MNPT, 316 Stainless Steel, Domestic

CBPN:88702

UPC:811731020126

MPN:SS-4-DMC-4

Price:
$9.41 / EA

DESCRIPTION

Tylok® CBC-Lok® Male Connector, Double Ferrule, Series: DMC, Fitting/Connector Type: Connector, 1/4 in Nominal Size, Tube x MNPT, 9/16 in Hex, 1.494 in Length, 316 Stainless Steel, Domestic

CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.

Tylok® CBC-Lok® SS-4-DMC-4 DMC Double Ferrule Male Connector, 1/4 in, Tube x MNPT, 316 Stainless Steel, Domestic

CBPN:88702

MPN:SS-4-DMC-4

UPC:811731020126

Price:
$9.41 / EA

Tylok logo

DESCRIPTION

Tylok® CBC-Lok® Male Connector, Double Ferrule, Series: DMC, Fitting/Connector Type: Connector, 1/4 in Nominal Size, Tube x MNPT, 9/16 in Hex, 1.494 in Length, 316 Stainless Steel, Domestic

CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.

Specifications

BrandTylok®
Weight0.07 lbs
Fitting/Connector TypeConnector
TypeDouble Ferrule
Nominal Size1/4 in
End StyleTube x MNPT
Material316 Stainless Steel
Hex Size9/16 in
Length1.494 in
Manufacturer NameTylok International
SeriesDMC
Warranty12 Months Limited
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsASTM A276/ASME-SA-479/Type 316-SS Bar Stock | ASME-SA-182/Type 316-SS Forging | ASTM A213/ASTM A269 Tubing | ABS | ASTM F1387 | Canadian Registration | ISO 9001:2008

Item Features

  • Double ferrule swaging action
  • Total component interchangeability
  • Heat code traceable
  • ASTM material construction
  • 9/16 in nut
  • 1/4-18 NPT pipe thread
  • 90 Rb hardness
  • Interchanges with 400-1-4 and 4MSC4N
