Tylok® CBC-Lok® SS-10-DATPM-8 DATPM Double ferrule Straight Adapter, 5/8 x 1/2 in, Tube x MNPT, Stainless Steel, Domestic
CBPN: 182148
UPC:811731028108
MPN:SS-10-DATPM-8
DESCRIPTION
Tylok® CBC-Lok® Straight Adapter, Double ferrule, Series: DATPM, Fitting/Connector Type: Adapter, 5/8 x 1/2 in Nominal, Tube x MNPT, 7/8 in Body Hex, 2.062 in Length, -20 to 1000 deg F, Stainless Steel, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although itis always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Tylok® CBC-Lok® SS-10-DATPM-8 DATPM Double ferrule Straight Adapter, 5/8 x 1/2 in, Tube x MNPT, Stainless Steel, Domestic
CBPN: 182148
MPN:SS-10-DATPM-8
UPC:811731028108
DESCRIPTION
Tylok® CBC-Lok® Straight Adapter, Double ferrule, Series: DATPM, Fitting/Connector Type: Adapter, 5/8 x 1/2 in Nominal, Tube x MNPT, 7/8 in Body Hex, 2.062 in Length, -20 to 1000 deg F, Stainless Steel, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although itis always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Specifications
Item Features
- Total component interchangeability
- Heat code traceable
- 90 Rb hardness
- 0.468 in thru hole
- Double ferrule swaging action system
