Tylok® CBC-Lok® B-8-DRPC-4 DRPC Double Ferrule Reducing Port Connector, 1/2 x 1/4 in, Tube, Brass, Domestic
CBPN:203794
UPC:815761021788
MPN:B-8-DRPC-4
Price:
$8.20 / EA
DESCRIPTION
Tylok® CBC-Lok® Reducing Port Connector, Double Ferrule, Series: DRPC, Fitting/Connector Type: Connector, 1/2 x 1/4 in Nominal Size, Tube, 1.234 in Length, Brass, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Tylok® CBC-Lok® B-8-DRPC-4 DRPC Double Ferrule Reducing Port Connector, 1/2 x 1/4 in, Tube, Brass, Domestic
CBPN:203794
MPN:B-8-DRPC-4
UPC:815761021788
Price:
$8.20 / EA
DESCRIPTION
Tylok® CBC-Lok® Reducing Port Connector, Double Ferrule, Series: DRPC, Fitting/Connector Type: Connector, 1/2 x 1/4 in Nominal Size, Tube, 1.234 in Length, Brass, Domestic
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
Specifications
Brand: Tylok®
Weight: 0.04lbs
End Style: Tube
Length: 1.234 in
Material: Brass
Nominal Size: 1/2 x 1/4 in
Series: DRPC
Type: Double Ferrule
Fitting/Connector Type: Connector
Manufacturer Name: Tylok International
Warranty: 12 Months Limited
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM B16 Alloy 360/ASTM B453 Alloy 345 Bar Stock | ASTM B124 Alloy 377 Forging | ASTM B75 Copper Temper (O) Tubing | ABS | ASTM F1387 | Canadian Registration | ISO 9001:2008
Item Features
- Double ferrule swaging action
- Total component interchangeability
- Heat code traceable
- ASTM material construction
- 1/4-18 NPT pipe thread
- 60 max rockwell 15 T hardness
- Interchanges with 811-PC-4 and 4PC8
