Spirax Sarco Pivotrol® 72886.3 PTF-HTF Pressure Powered Pump With Check Valve, Fabricated Steel Body, 3 in Inlet x 2 in Outlet, ANSI 300 Flanged Connection
CBPN: 239046
MPN:72886.3
DESCRIPTION
Spirax Sarco Pivotrol® Pressure Powered Pump, 90 gpm, 3 in Inlet, 2 in Outlet, Socket Weld/ANSI 300 Flanged, 200 psig Operating Maximum, Stainless Steel Float, 400 deg F Operating, Fabricated Steel Body, 30 in L x 34.6 in H
The Spirax Sarco Pivotrol® Pump(patented), featuring reliable PowerPivot® technology (patented) is specifically designed for use on heat transfer fluids, with specific gravity of 0.65 to 0.79, in a closed loop system. This self-contained unit uses the pressurized heat transfer fluid vapor phase as the pumping force to transport condensed heat transfer fluid from a low point, or low pressure space to an area of high pressure or elevation. Suitable for use in hazardous environments and volatile fluid pumping applications.
Spirax Sarco Pivotrol® 72886.3 PTF-HTF Pressure Powered Pump With Check Valve, Fabricated Steel Body, 3 in Inlet x 2 in Outlet, ANSI 300 Flanged Connection
CBPN: 239046
MPN:72886.3
DESCRIPTION
Spirax Sarco Pivotrol® Pressure Powered Pump, 90 gpm, 3 in Inlet, 2 in Outlet, Socket Weld/ANSI 300 Flanged, 200 psig Operating Maximum, Stainless Steel Float, 400 deg F Operating, Fabricated Steel Body, 30 in L x 34.6 in H
The Spirax Sarco Pivotrol® Pump(patented), featuring reliable PowerPivot® technology (patented) is specifically designed for use on heat transfer fluids, with specific gravity of 0.65 to 0.79, in a closed loop system. This self-contained unit uses the pressurized heat transfer fluid vapor phase as the pumping force to transport condensed heat transfer fluid from a low point, or low pressure space to an area of high pressure or elevation. Suitable for use in hazardous environments and volatile fluid pumping applications.
Specifications
Item Features
- ANSI 300 RF with surface finish 125-250u in serrated concentric or spiral grooves per ANSI B16.5 connection
- SW ANSI B16.11 motive and exhaust connection
- 8.4 gal nominal pump discharge per cycle
- 5 psig minimum motive differential pressure
- 200 psig at 750 deg F maximum allowable pressure
- 750 deg F at 200 psig maximum allowable temperature
- Stainless steel check valve
- For use on heat transfer fluids in a closed loop system
- Socket weld cover
- 0.65 to 0.79 specific gravity
- 6 maximum number of cycles per minute
