Spirax Sarco 60976, FA-200 Liquid Drain Trap, 1-1/2 in, NPT, 10-3/4 in L, 200 psig Operating, Cast Iron
CBPN:191262
MPN:60976
Price:
$1992.90 / EA
DESCRIPTION
Spirax Sarco Liquid Drain Trap, 1-1/2 in Nominal, NPT, 10-3/4 in Length, 200 psig Operating, Cast Iron, 450 deg F Operating, 9.1 in H
The float-operated liquid drain trap discharges continuously in direct response to variations in liquid flow rate, assuring thorough drainage of the system.
Spirax Sarco 60976, FA-200 Liquid Drain Trap, 1-1/2 in, NPT, 10-3/4 in L, 200 psig Operating, Cast Iron
CBPN:191262
MPN:60976
Price:
$1992.90 / EA
DESCRIPTION
Spirax Sarco Liquid Drain Trap, 1-1/2 in Nominal, NPT, 10-3/4 in Length, 200 psig Operating, Cast Iron, 450 deg F Operating, 9.1 in H
The float-operated liquid drain trap discharges continuously in direct response to variations in liquid flow rate, assuring thorough drainage of the system.
Specifications
Brand: Spirax Sarco
Weight: 30lbs
End Style: NPT
Length: 10-3/4 in
Material: Cast Iron
Nominal Size: 1-1/2 in
Series: FA-200
Temperature Rating: 450 deg F Operating
Pressure Rating: 200 psig Operating
Dimensions: 9.1 in H
Manufacturer Name: Spirax-Sarco Inc
Application: Receiver and air line drainage, draining a liquid from its vapor phase
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM A126 Class B Body
Item Features
- Maximum allowable pressure: 200 psig at 0 to 450 deg F
- Maximum allowable temperature: 450 deg F at 0 to 200 psig
- 1-1/2 in trap
- 6000 lb/hr load at maximum operating pressure
- Parallel piping configuration
