Spirax Sarco 0441391, SBRA Reverse Acting Temperature Regulator Valve, 3/4 in, FNPT End Style, 7 bar
CBPN: 63323
MPN:0441391
Price:
$1071.07 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Reverse Acting, 3/4 in Nominal, NPT, 7 bar, Bronze Body, Stainless Steel Trim, 3.7 in L
Spirax Sarco 0441391, SBRA Reverse Acting Temperature Regulator Valve, 3/4 in, FNPT End Style, 7 bar
CBPN: 63323
MPN:0441391
Price:
$1071.07 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Reverse Acting, 3/4 in Nominal, NPT, 7 bar, Bronze Body, Stainless Steel Trim, 3.7 in L
Specifications
Brand: Spirax Sarco
Weight: 3 lbs
Nominal Size: 3/4 in
End Style: FNPT
Pressure Rating: 7 bar
Body Material: Bronze
Dimensions: 3.7 in L
Manufacturer Name: Spirax-Sarco Inc
Series: SBRA
Trim Material: Stainless Steel
Type: Reverse Acting
Application: Industrial/Commercial
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Class IV Shut-Off | BS 1400 LG2 Body
Item Features
- Maximum allowable temperature: 500 deg F at 0 to 152 psig
- 4.5 Cv
- 8 deg p-band
- Differential pressure: 101 psi
- 2-port
- Maximum allowable pressure: 362 psig at 248 deg F
- 4 mm stroke
- 3.7 in inlet center to top
- Horizontal installation
- Normally closed, opens with rising temperature for cooling
- Single seat with optional 1/8 in (Cv .44) bleed bypass and optional fusible devise
