Spirax Sarco 0440490, SB Direct Acting Temperature Regulator Valve, 1/2 in, FNPT End Style, 17.2 bar
CBPN: 7552
MPN:0440490
Price:
$455.00 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Direct Acting, Series: SB Series, 1/2 in Nominal, NPT End Style, 17.2 bar Pressure, Bronze Body, Stainless Steel Trim, 3.1 in L Dimensions, Domestic
Spirax Sarco 0440490, SB Direct Acting Temperature Regulator Valve, 1/2 in, FNPT End Style, 17.2 bar
CBPN: 7552
MPN:0440490
Price:
$455.00 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Direct Acting, Series: SB Series, 1/2 in Nominal, NPT End Style, 17.2 bar Pressure, Bronze Body, Stainless Steel Trim, 3.1 in L Dimensions, Domestic
Specifications
Brand: Spirax Sarco
Weight: 2.3 lbs
Nominal Size: 1/2 in
End Style: FNPT
Pressure Rating: 17.2 bar
Body Material: Bronze
Dimensions: 3.1 in L
Manufacturer Name: Spirax-Sarco Inc
Series: SB Series
Trim Material: Stainless Steel
Type: Direct Acting
Application: Industrial/Commercial
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Class IV Shut-Off | BS 1400 LG2 Body
Item Features
- Maximum allowable temperature: 500 deg F at 0 to 152 psig
- 3 Cv
- 8 deg p-band
- Differential pressure: 250 psi
- 2-port
- Maximum allowable pressure: 362 psig at 248 deg F
- 3.2 mm stroke
- 2 in inlet center to top
- Horizontal installation
- Normally open, closes with temperature rise for heating, single seat
- On liquid applications, the permissible maximum differential pressure may be affected by high static pressure
