Spirax Sarco 0440390 SBRA Normally Closed Self Acting Temperature Control Valve, 1/2 in Nominal, FNPT End Style, 0 to 260 deg C, 25 bar g Pressure
CBPN: 271877
MPN:0440390
Price:
$1097.46 / EA
DESCRIPTION
Spirax Sarco Temperature Control Valve, Normally Closed Self Acting, Series: SBRA, 1/2 in Nominal, NPT End Style, 0 to 260 deg C, 25 bar g Pressure, Gunmetal Body, Brass Trim, Graphite Softgoods, 79 mm L Dimensions
The SB and SBRA range of two port valve are used in conjunction with Spirax Sarco SA control systems to provide a self-acting temperature control unit.
Spirax Sarco 0440390 SBRA Normally Closed Self Acting Temperature Control Valve, 1/2 in Nominal, FNPT End Style, 0 to 260 deg C, 25 bar g Pressure
CBPN: 271877
MPN:0440390
Price:
$1097.46 / EA
DESCRIPTION
Spirax Sarco Temperature Control Valve, Normally Closed Self Acting, Series: SBRA, 1/2 in Nominal, NPT End Style, 0 to 260 deg C, 25 bar g Pressure, Gunmetal Body, Brass Trim, Graphite Softgoods, 79 mm L Dimensions
The SB and SBRA range of two port valve are used in conjunction with Spirax Sarco SA control systems to provide a self-acting temperature control unit.
Specifications
Brand: Spirax Sarco
Weight: 15 lbs
Nominal Size: 1/2 in
End Style: FNPT
Temperature Rating: 0 to 260 deg C
Pressure Rating: 25 bar g
Body Material: Gunmetal
Dimensions: 79 mm L
Manufacturer Name: Spirax-Sarco Inc
Series: SBRA
Softgoods Material: Graphite
Trim Material: Brass
Type: Normally Closed Self Acting
Standards and Approvals: ASTM BS 1400 LG2 | CE Certified | European Pressure Equipment Directive
Item Features
- Accurate
- Reliable
- Easy-to-use
- Easy-to-install
- Easy-to-commission
- Brass stem
- Reinforced exfoliated graphite bonnet gasket
