Spears® 867S-664CSR Clamp-On Pipe Saddle, 12 x 4 in Nominal, Special Reinforced FNPT Connection, 4 in Dia Hole, CPVC Clamp, Domestic
CBPN: 236287
UPC:054211022771
MPN:867S-664CSR
Price:
$1263.59 / EA
DESCRIPTION
Spears® Pipe Saddle, Clamp-On, 12 x 4 in Nominal, Special Reinforced FNPT Connection, 4 in Diameter Hole, SCH 80/XH Schedule, 150 psi Pressure, 73 deg F, Stainless Steel Bolt, CPVC Clamp, 14-5/16 in W Dimensions, Gray, Domestic/Import: Domestic
Spears® 867S-664CSR Clamp-On Pipe Saddle, 12 x 4 in Nominal, Special Reinforced FNPT Connection, 4 in Dia Hole, CPVC Clamp, Domestic
CBPN: 236287
MPN:867S-664CSR
UPC:054211022771
Price:
$1263.59 / EA
DESCRIPTION
Spears® Pipe Saddle, Clamp-On, 12 x 4 in Nominal, Special Reinforced FNPT Connection, 4 in Diameter Hole, SCH 80/XH Schedule, 150 psi Pressure, 73 deg F, Stainless Steel Bolt, CPVC Clamp, 14-5/16 in W Dimensions, Gray, Domestic/Import: Domestic
Specifications
Brand: Spears®
Weight: 16.62 lbs
Nominal Size: 12 x 4 in
Connection Type: Special Reinforced FNPT
Clamp Material: CPVC
Schedule Rating: SCH 80/XH
Bolt Material: Stainless Steel
Color: Gray
Dimensions: 14-5/16 in W
Hole Diameter: 4 in
Manufacturer Name: Spears Manufacturing
Pressure Rating: 150 psi
Temperature Rating: 73 deg F
Type: Clamp-On
Domestic/Import: Domestic
Country of Origin: US
Item Features
- 4 in Dia hole saw
- Molded CPVC
- 4 in hole
