Spears® 8171-015 Standard Tank Adapter With Neoprene Gasket, 1-1/2 in Nominal, Socket x FNPT End Style, 2-3/4 in Hole, PVC, Domestic
CBPN:41702
UPC:054211948576
MPN:8171-015
Price:
$80.13 / EA
DESCRIPTION
Spears® Tank Adapter, Standard, Connector Fitting/Connector, 1-1/2 in Nominal, Socket x FNPT End Style, 2-3/4 in Hole, 3-5/8 in Length, SCH 80/XH Schedule, 150 psi Pressure, Molded Method of Manufacture, PVC, Gray, Domestic
All PVC schedule 80 fittings shall be produced by Spears® manufacturing company from PVC Type I, cell classification 12454, conforming to ASTM Standard D1784. All injection molded PVC schedule 80 fittings shall be certified for potable water service by NSF® International manufactured in strict compliance to ASTM D 2467. All fabricated fittings shall be produced in accordance with Spears® general specifications for fabricated fittings. All PVC flanges shall be designed and manufactured to meet CL150 bolt pattern per ANSI standard B16.5 and rated for a maximum internal pressure of 150 psi, non-shock at 73 deg F.
Spears® 8171-015 Standard Tank Adapter With Neoprene Gasket, 1-1/2 in Nominal, Socket x FNPT End Style, 2-3/4 in Hole, PVC, Domestic
CBPN:41702
MPN:8171-015
UPC:054211948576
Price:
$80.13 / EA
DESCRIPTION
Spears® Tank Adapter, Standard, Connector Fitting/Connector, 1-1/2 in Nominal, Socket x FNPT End Style, 2-3/4 in Hole, 3-5/8 in Length, SCH 80/XH Schedule, 150 psi Pressure, Molded Method of Manufacture, PVC, Gray, Domestic
All PVC schedule 80 fittings shall be produced by Spears® manufacturing company from PVC Type I, cell classification 12454, conforming to ASTM Standard D1784. All injection molded PVC schedule 80 fittings shall be certified for potable water service by NSF® International manufactured in strict compliance to ASTM D 2467. All fabricated fittings shall be produced in accordance with Spears® general specifications for fabricated fittings. All PVC flanges shall be designed and manufactured to meet CL150 bolt pattern per ANSI standard B16.5 and rated for a maximum internal pressure of 150 psi, non-shock at 73 deg F.
Specifications
Brand: Spears®
Weight: 0.68lbs
End Style: Socket x FNPT
Length: 3-5/8 in
Material: PVC
Nominal Size: 1-1/2 in
Type: Standard
Color: Gray
Fitting/Connector Type: Connector
Hole Size: 2-3/4 in
Pressure Rating: 150 psi
Schedule Rating: SCH 80/XH
Method of Manufacture: Molded
Manufacturer Name: Spears Manufacturing
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM Specified | NSF Approved
