Spears® 5691-002P Angle Pattern Needle Valve, 1/4 in Nominal, FNPT End Style, Polypropylene Body, Domestic
CBPN: 261147
UPC:054211540442
MPN:5691-002P
DESCRIPTION
Spears® Needle Valve, Angle Pattern, 1/4 in Nominal, FNPT, 150 psi, 176 deg F, Handle Actuator, 1-3/16 in Inlet to Outlet Length, 3 to 3-1/2 in Top to Inlet Center, Polypropylene Body, GFPP Trim, PTFE Stem Seal, Natural, Domestic
Needle valves provide proportional opening to needle travel for more accurate metering applications and other fine adjustment flow control applications. Special design PTFE seal eliminates elastomer type seals or O-rings that can contribute to chemical compatibility problems. PVC, CPVC and Polypropylene valves are available with 1/4 in, 3/8 in and 1/2 in NPT female threaded ends in either standard globe pattern or special angle pattern configuration that eliminates need for additional elbow in various system setups.
Spears® 5691-002P Angle Pattern Needle Valve, 1/4 in Nominal, FNPT End Style, Polypropylene Body, Domestic
CBPN: 261147
MPN:5691-002P
UPC:054211540442
DESCRIPTION
Spears® Needle Valve, Angle Pattern, 1/4 in Nominal, FNPT, 150 psi, 176 deg F, Handle Actuator, 1-3/16 in Inlet to Outlet Length, 3 to 3-1/2 in Top to Inlet Center, Polypropylene Body, GFPP Trim, PTFE Stem Seal, Natural, Domestic
Needle valves provide proportional opening to needle travel for more accurate metering applications and other fine adjustment flow control applications. Special design PTFE seal eliminates elastomer type seals or O-rings that can contribute to chemical compatibility problems. PVC, CPVC and Polypropylene valves are available with 1/4 in, 3/8 in and 1/2 in NPT female threaded ends in either standard globe pattern or special angle pattern configuration that eliminates need for additional elbow in various system setups.
Specifications
Item Features
- Chemical and corrosion resistant PVC, CPVC or PP construction
- Precision metering chamber
- Globe and angle body configurations
- Removable bonnet for easy disassembly and cleaning
- Built-In panel or bracket mounting nut
- Solid PTFE stem seal-no elastomers seal or lubricants used
- Easy grip polypropylene handle
