Spears® 5420-040C Butterfly Check Valve, 4 in, Wafer, CPVC Body, EPDM Softgoods, Domestic
CBPN:201389
UPC:054211454527
MPN:5420-040C
Price:
$2335.91 / EA
DESCRIPTION
Spears® Butterfly Check Valve, 4 in Nominal, Wafer, 150 psi, 200 deg F, 3-5/8 in Inlet to Outlet Length, CPVC Body, Softgoods Material: EPDM, Gray, 6-5/8 in OD, Domestic
Spears® multi-purpose butterfly check valves provide an extremely low profile and very quick response to back flow without slamming. Since most all components are internal, Spears® butterfly check valves require no more space than a piece of pipe and fitting. Special design incorporates flexible reinforced elastomer seal for long life and is suitable for mounting in any position for greater versatility. Available in IPS sizes 2 to 12 in with Flanged, Spigot, Male Threaded, Grooved pipe style and Wafer end connections, and 14 to 24 in Flanged, Spigot, Grooved and Wafer end connections. Can be custom produced to virtually any standard pipe Diameter.
Spears® 5420-040C Butterfly Check Valve, 4 in, Wafer, CPVC Body, EPDM Softgoods, Domestic
CBPN:201389
MPN:5420-040C
UPC:054211454527
Price:
$2335.91 / EA
DESCRIPTION
Spears® Butterfly Check Valve, 4 in Nominal, Wafer, 150 psi, 200 deg F, 3-5/8 in Inlet to Outlet Length, CPVC Body, Softgoods Material: EPDM, Gray, 6-5/8 in OD, Domestic
Spears® multi-purpose butterfly check valves provide an extremely low profile and very quick response to back flow without slamming. Since most all components are internal, Spears® butterfly check valves require no more space than a piece of pipe and fitting. Special design incorporates flexible reinforced elastomer seal for long life and is suitable for mounting in any position for greater versatility. Available in IPS sizes 2 to 12 in with Flanged, Spigot, Male Threaded, Grooved pipe style and Wafer end connections, and 14 to 24 in Flanged, Spigot, Grooved and Wafer end connections. Can be custom produced to virtually any standard pipe Diameter.
Specifications
Brand: Spears®
Weight: 2.75lbs
Body Material: CPVC
End Style: Wafer
Nominal Size: 4 in
Temperature Rating: 200 deg F
Color: Gray
Pressure Rating: 150 psi
Dimensions: 6-5/8 in OD
Softgoods Material: EPDM
Inlet to Outlet Length: 3-5/8 in
Manufacturer Name: Spears Manufacturing
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Specified
Item Features
- Chemical resistant PVC and CPVC construction
- Maximum PVC and CPVC service temperature
- Quick response shut-off in any position
- Molded method of manufacture
- EPDM O-ring
