Spears® 2622-060G

Spears® 2622-060G 1-Piece Utility Ball Valve, 6 in, Socket End Style, PVC Body, EPDM Softgoods, Domestic

CBPN: 237729

UPC:054211202272

MPN:2622-060G

Price:
$668.83 / EA

DESCRIPTION

Spears® Ball Valve, 1-Piece Utility, 6 in Nominal, Socket, 150 psi, 73 deg F, PVC Ball, 14-3/16 in Inlet to Outlet Length, 8-5/32 in Top to Inlet Center, PVC Body, EPDM Softgoods, Domestic

A high quality, economical quarter-turn shut-off valve designed for irrigation, pool and spa, and general purpose applications. IPS sizes 1/2 to 2 in available in PVC White, PVC Gray or CPVC with socket or threaded end connectors. Sizes 3 to 4 in available in PVC White with socket or threaded end connectors. 6 in size available in PVC White with socket end connectors and high efficiency lever style handle for easier operation.

Spears® 2622-060G 1-Piece Utility Ball Valve, 6 in, Socket End Style, PVC Body, EPDM Softgoods, Domestic

CBPN: 237729

MPN:2622-060G

UPC:054211202272

Price:
$668.83 / EA

Spears logo

DESCRIPTION

Spears® Ball Valve, 1-Piece Utility, 6 in Nominal, Socket, 150 psi, 73 deg F, PVC Ball, 14-3/16 in Inlet to Outlet Length, 8-5/32 in Top to Inlet Center, PVC Body, EPDM Softgoods, Domestic

A high quality, economical quarter-turn shut-off valve designed for irrigation, pool and spa, and general purpose applications. IPS sizes 1/2 to 2 in available in PVC White, PVC Gray or CPVC with socket or threaded end connectors. Sizes 3 to 4 in available in PVC White with socket or threaded end connectors. 6 in size available in PVC White with socket end connectors and high efficiency lever style handle for easier operation.

Specifications

Brand: Spears®
Weight: 24.9 lbs
Nominal Size: 6 in
End Style: Socket
Pressure Rating: 150 psi
Body Material: PVC
Softgoods Material: EPDM
Ball Material: PVC
Inlet to Outlet Length: 14-3/16 in
Manufacturer Name: Spears Manufacturing
Temperature Rating: 73 deg F
Top to Inlet Center: 8-5/32 in
Type: 1-Piece Utility
Application: Lawn Sprinklers, Pools, Spas, Water Gardens and other Light-duty
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM D1784 Cell Classification 12454 | NSF Approved | Loss Prevention Certification Board | UKAS Management System

Item Features

  • PTFE/HDPE ball seats: Smooth operating PTFE/HDPE floating seat design reduces wear
  • EPDM O-Ring seals: High grade, abrasion resistant EPDM elastomer O-Rings
  • Full SCH 80/XH bore - in full open position, full bore virtually eliminates pressure drop, providing optimum flow
  • High impact polypropylene handle
  • Safe-T-Shear® stem: Developed to help prevent line fluids from leaking out in the event of ball valve stem damage, engineered for high strength, the stem incorporates a special shear point to control accidental breakage, over torqueing breaks occur above the stem O-Ring leaving the seal intact until replacement can be made
  • EPDM O-ring
