Spears® 2123-005C Compact Regular Ball Valve, 1/2 in Nominal, Flanged End Style, CPVC Body, EPDM Softgoods, Domestic
CBPN: 236854
UPC:054211370537
MPN:2123-005C
Price:
$131.13 / EA
DESCRIPTION
Spears® Regular Ball Valve, Compact, 1/2 in Nominal, Flanged, 150 psi, 200 deg F, T-Handle Actuator, CPVC Ball, 2-5/16 in Top to Inlet Center, CPVC Body, CPVC Stem and PTFE Seat Trim, EPDM, Gray, Domestic
This heavy bodied, quarter-turn shut-off valve is popular where maintenance-free installations are desired for a variety of chemical, industrial and OEM applications. Factory-adjusted sealed units are available in IPS sizes 1/2 in through 2 in, with choice of either socket or threaded end connectors.
Spears® 2123-005C Compact Regular Ball Valve, 1/2 in Nominal, Flanged End Style, CPVC Body, EPDM Softgoods, Domestic
CBPN: 236854
MPN:2123-005C
UPC:054211370537
Price:
$131.13 / EA
DESCRIPTION
Spears® Regular Ball Valve, Compact, 1/2 in Nominal, Flanged, 150 psi, 200 deg F, T-Handle Actuator, CPVC Ball, 2-5/16 in Top to Inlet Center, CPVC Body, CPVC Stem and PTFE Seat Trim, EPDM, Gray, Domestic
This heavy bodied, quarter-turn shut-off valve is popular where maintenance-free installations are desired for a variety of chemical, industrial and OEM applications. Factory-adjusted sealed units are available in IPS sizes 1/2 in through 2 in, with choice of either socket or threaded end connectors.
Specifications
Brand: Spears®
Weight: 0.75 lbs
Nominal Size: 1/2 in
End Style: ANSI 150 Flange
Pressure Rating: 150 psi
Body Material: CPVC
Softgoods Material: EPDM
Actuator Type: T-Handle
Ball Material: CPVC
Color: Gray
Manufacturer Name: Spears Manufacturing
Temperature Rating: 200 deg F
Top to Inlet Center: 2-5/16 in
Trim Material: CPVC Stem and PTFE Seat
Type: Compact
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM F1970 | NSF Approved
Item Features
- Heavy bodied PVC or CPVC construction
- High impact polypropylene handle
- Full SCH 80/XH bore
- Safe-T-Shear® stem
- EPDM O-ring
