Spears® 2011-005C Gate Valve, 1/2 in Nominal, FNPT End Style, CPVC Body, Buna-N Softgoods, Handwheel Actuator, Domestic
CBPN:261299
UPC:054211519202
MPN:2011-005C
Price:
$122.04 / EA
DESCRIPTION
Spears® Gate Valve, 1/2 in Nominal, FNPT End Style, 200 psi Pressure, 200 deg F, Handwheel Actuator, 2-13/16 in Inlet to Outlet Length, 4-1/8 in Top to Inlet Center, CPVC Body, CPVC Trim, Buna-N O-Ring Softgoods, 2-5/8 in Diameter Hand Wheel, Gray, Domestic
This solid, proven design is well suited for a variety of chemical, industrial and irrigation applications. Spears® Gate Valves are feature-packed with a variety of end connector options. Individual special features are found in each size range 1/2 in through 2 in, 2-1/2 in and 3 in, and in the full featured Heavy Industrial 4 in valve. See Spears® plug gate valves for 6 in size.
Spears® 2011-005C Gate Valve, 1/2 in Nominal, FNPT End Style, CPVC Body, Buna-N Softgoods, Handwheel Actuator, Domestic
CBPN:261299
MPN:2011-005C
UPC:054211519202
Price:
$122.04 / EA
DESCRIPTION
Spears® Gate Valve, 1/2 in Nominal, FNPT End Style, 200 psi Pressure, 200 deg F, Handwheel Actuator, 2-13/16 in Inlet to Outlet Length, 4-1/8 in Top to Inlet Center, CPVC Body, CPVC Trim, Buna-N O-Ring Softgoods, 2-5/8 in Diameter Hand Wheel, Gray, Domestic
This solid, proven design is well suited for a variety of chemical, industrial and irrigation applications. Spears® Gate Valves are feature-packed with a variety of end connector options. Individual special features are found in each size range 1/2 in through 2 in, 2-1/2 in and 3 in, and in the full featured Heavy Industrial 4 in valve. See Spears® plug gate valves for 6 in size.
Specifications
Brand: Spears®
Weight: 0.56lbs
Actuator Type: Handwheel
Body Material: CPVC
End Style: FNPT
Nominal Size: 1/2 in
Temperature Rating: 200 deg F
Color: Gray
Pressure Rating: 200 psi
Softgoods Material: Buna-N® O-Ring
Trim Material: CPVC
Hand Wheel Diameter: 2-5/8 in
Inlet to Outlet Length: 2-13/16 in
Manufacturer Name: Spears Manufacturing
Top to Inlet Center: 4-1/8 in
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM Specified | NSF Approved
Item Features
- Tapered wedge with specially designed sealing surface
- Non-rising stem design
- O-ring stem seals instead of packing
- Positive grip, high impact polypropylene handwheel operator
- Fully serviceable, replaceable components accessible without valve removal
- SCH 80
