Dixon® G400-F-AL Type F Cam and Groove Adapter, 4 in, Male Adapter x MNPT, Aluminum, Import
CBPN: 183514
MPN:G400-F-AL
Price:
$41.75 / EA
Prop 65:
DESCRIPTION
Dixon® Cam and Groove Adapter, Type F, Fitting/Connector Type: Adapter, 4 in Nominal Size, Male Adapter x MNPT, 4-1/2 in Length, 100 psi, Aluminum, 4-23/32 in Dia, Import
Dixon® G400-F-AL Type F Cam and Groove Adapter, 4 in, Male Adapter x MNPT, Aluminum, Import
CBPN: 183514
MPN:G400-F-AL
Price:
$41.75 / EA
Prop 65:
DESCRIPTION
Dixon® Cam and Groove Adapter, Type F, Fitting/Connector Type: Adapter, 4 in Nominal Size, Male Adapter x MNPT, 4-1/2 in Length, 100 psi, Aluminum, 4-23/32 in Dia, Import
Specifications
Brand: Dixon®
Weight: 1.98 lbs
Fitting/Connector Type: Adapter
Type: Type F
Nominal Size: 4 in
End Style: Male Adapter x MNPT
Material: Aluminum
Dimensions: 4-23/32 in Dia
Length: 4-1/2 in
Manufacturer Name: Dixon Valve & Coupling
Pressure Rating: 100 psi
Application: Designed for use with liquids
Warranty: Limited
Domestic/Import: Import
Country of Origin: CN
Item Features
- Designed to interchange with all products produced to A-A-59326D
- Made to Dixon specifications and branded Dixon
- For use with liquid
- A380 permanent mold aluminum
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating is based on the seal of the mating part
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
- 100 psi at ambient temperature 70 deg F pressure
- Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
