Dixon® G100-A-AL Type A Cam and Groove Adapter, 1 in, Male Adapter x FNPT, Aluminum
CBPN:183502
MPN:G100-A-AL
Price:
$6.74Â /Â EA
DESCRIPTION
Dixon® Cam and Groove Adapter, Type A, Fitting/Connector Type: Adapter, 1 in Nominal Size, Male Adapter x FNPT, 1-29/32 in Length, 250 psi, Aluminum
Dixon® G100-A-AL Type A Cam and Groove Adapter, 1 in, Male Adapter x FNPT, Aluminum
CBPN:183502
MPN:G100-A-AL
Price:
$6.74Â /Â EA
Â
Specifications
Brand: Dixon®
Weight:Â 0.12lbs
End Style:Â Male Adapter x FNPT
Length:Â 1-29/32 in
Material:Â Aluminum
Nominal Size:Â 1 in
Type:Â Type A
Fitting/Connector Type:Â Adapter
Pressure Rating:Â 250 psi
Manufacturer Name:Â Dixon Valve & Coupling
Application:Â Designed for use with liquids
Warranty:Â Limited
Item Features
- Interchange with all products produced to A-A-59326D
- Made to Dixon specifications and branded Dixon
- Buna seals are standard
- Pressure rating for adapters is based on the seal of the mating part
- A380 permanent mold aluminum
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating is based on the seal of the mating part
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
- 250 psi at ambient temperature 70 deg F pressure
- Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
- http://youtu.be/Vgth_9M5IRM?list=PL10BD55ADAF82DEDA
