CRANE® 7TF-3 Globe Valve, 3 in Nominal, FNPT End Style, 150 lb, Bronze Body, Handwheel Actuator
CBPN: 36079
MPN:7TF-3
Price:
$4706.42 / EA
DESCRIPTION
CRANE® Globe Valve, Series: 7TF, 3 in Nominal, Thread End Style, 150 lb Pressure Class, Handwheel Actuator, 8-1/2 in Inlet to Outlet Length, 10-1/4 in Top to Inlet Center, Bronze Body, Bronze Trim, Synthetic Glass Fiber with Nitrile Binder Gasket/Graphite Asbestos-Free Packing Softgoods, 5.98 in Diameter Hand Wheel
**This item may be subject to a minimum order quantity.**
CRANE® 7TF-3 Globe Valve, 3 in Nominal, FNPT End Style, 150 lb, Bronze Body, Handwheel Actuator
CBPN: 36079
MPN:7TF-3
Price:
$4706.42 / EA
DESCRIPTION
CRANE® Globe Valve, Series: 7TF, 3 in Nominal, Thread End Style, 150 lb Pressure Class, Handwheel Actuator, 8-1/2 in Inlet to Outlet Length, 10-1/4 in Top to Inlet Center, Bronze Body, Bronze Trim, Synthetic Glass Fiber with Nitrile Binder Gasket/Graphite Asbestos-Free Packing Softgoods, 5.98 in Diameter Hand Wheel
**This item may be subject to a minimum order quantity.**
Specifications
Brand: CRANE®
Weight: 33.22 lbs
Nominal Size: 3 in
End Style: FNPT
Pressure Class: 150 lb
Body Material: Bronze
Actuator Type: Handwheel
Hand Wheel Diameter: 5.98 in
Inlet to Outlet Length: 8-1/2 in
Manufacturer Name: Crane ChemPharma Energy
Series: 7TF
Softgoods Material: Synthetic Glass Fiber with Nitrile Binder Gasket/Graphite Asbestos-Free Packing
Top to Inlet Center: 10-1/4 in
Trim Material: Bronze
Application: Marine, General Services Plumbing, Commercial Plumbing, Industrial Plumbing and HVAC
Standards and Approvals: ASTM B62 C83600 Body | ASTM B371 C69400 Stem | ASTM B16 H02 Bonnet | MSS SP-80 | Type 1
Item Features
- Full pressure class offering: Class 125, Class 150, class 200, Class 300, 200 CWP and 300 CWP
- Wide option range seat, disc, trims, and connection type
- Bolted bonnets
- PTFE disc
