Apollo™ 94-MBV-03 2-Piece Instrumentation Ball Valve, 1/4 in Nominal, FNPT End Style, Brass Body, Full Port, Fluorocarbon Softgoods
CBPN: 121203
UPC:670750241314
MPN:94MBV03
Price:
$20.64 / EA
Prop 65:
DESCRIPTION
Apollo™ Apollo International™ Ball Valve, 2-Piece Instrumentation, Series: 94MBV, 1/4 in Nominal, FNPT x FNPT End Style, 600 psi Pressure, -40 to 300 deg F, Full Port, Reversible Handle Actuator, Chrome Plated Brass Ball, 1.95 in Inlet to Outlet Length, 1.09 in Top to Inlet Center, Brass Body, Brass Stem and TFE Seat Trim, Fluorocarbon Softgoods
The 94MBV Series is a heavy pattern 2-Piece forged brass full port ball valve designed for water, oil or gas in commercial and light industrial applications.
Apollo™ 94-MBV-03 2-Piece Instrumentation Ball Valve, 1/4 in Nominal, FNPT End Style, Brass Body, Full Port, Fluorocarbon Softgoods
CBPN: 121203
MPN:94MBV03
UPC:670750241314
Price:
$20.64 / EA
Prop 65:
DESCRIPTION
Apollo™ Apollo International™ Ball Valve, 2-Piece Instrumentation, Series: 94MBV, 1/4 in Nominal, FNPT x FNPT End Style, 600 psi Pressure, -40 to 300 deg F, Full Port, Reversible Handle Actuator, Chrome Plated Brass Ball, 1.95 in Inlet to Outlet Length, 1.09 in Top to Inlet Center, Brass Body, Brass Stem and TFE Seat Trim, Fluorocarbon Softgoods
The 94MBV Series is a heavy pattern 2-Piece forged brass full port ball valve designed for water, oil or gas in commercial and light industrial applications.
Specifications
Brand: Apollo™
Weight: 0.17 lbs
Nominal Size: 1/4 in
End Style: FNPT
Pressure Rating: 600 psi
Body Material: Brass
Port Type: Full
Softgoods Material: Fluorocarbon
Actuator Type: Reversible Handle
Ball Material: Chrome Plated Brass
Inlet to Outlet Length: 1.68 in
Manufacturer Name: Apollo Conbraco
Series: 94MBV
Temperature Rating: -40 to 300 deg F
Top to Inlet Center: 1.09 in
Trim Material: Brass Stem and TFE Seat
Type: 2-Piece
Application: Designed For Water, Oil Or Gas In Commercial And Light Industrial Applications
Warranty: 2 Years
Standards and Approvals: ANSI Z21.15-2009/CSA 9.1-2009 (1/2 psi) Manually Operated Gas Valves for Appliances | ASME B16.44-2002 | MSS-SP-110 | PROP65: Cancer and Reproductive Harm
Item Features
- Multiple connection options
- Rugged forged construction
- Blow-out proof stem
- Large raised wrench flats
- Optimum flow rate
- 600 psi at 100 deg F maximum
- Brass plated steel handle nut
- Zinc plated steel with vinyl handle
- Brass packing nut
- Fluorocarbon O-ring
