Apollo™ 94MBV02

Apollo™ 94-MBV-02 2-Piece Instrumentation Ball Valve, 1/4 in Nominal, MNPT x FNPT End Style, Brass Body, Full Port, Fluorocarbon Softgoods

CBPN:98284

UPC:670750241154

MPN:94MBV02

Price:
$13.47 / EA
Prop 65:

DESCRIPTION

Apollo™, 94MBV02, Instrumentation Ball Valve, 2-Piece, Series: 94MBV, 1/4 in Nominal, MNPT x FNPT End Style, 600 psi Pressure, -40 to 300 deg F, Full Port, Reversible Handle Actuator, 1.95 in Inlet to Outlet Length, 1.09 in Top to Inlet Center, Brass Stem and TFE Seat Trim, Fluorocarbon Softgoods

The 94MBV Series is a heavy pattern 2-Piece forged brass full port ball valve designed for water, oil or gas in commercial and light industrial applications.

Apollo™ 94-MBV-02 2-Piece Instrumentation Ball Valve, 1/4 in Nominal, MNPT x FNPT End Style, Brass Body, Full Port, Fluorocarbon Softgoods

CBPN:98284

MPN:94MBV02

UPC:670750241154

Price:
$13.47 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™, 94MBV02, Instrumentation Ball Valve, 2-Piece, Series: 94MBV, 1/4 in Nominal, MNPT x FNPT End Style, 600 psi Pressure, -40 to 300 deg F, Full Port, Reversible Handle Actuator, 1.95 in Inlet to Outlet Length, 1.09 in Top to Inlet Center, Brass Stem and TFE Seat Trim, Fluorocarbon Softgoods

The 94MBV Series is a heavy pattern 2-Piece forged brass full port ball valve designed for water, oil or gas in commercial and light industrial applications.

Specifications

BrandApollo™
Weight0.2lbs
Actuator TypeReversible Handle
Body MaterialBrass
End StyleMNPT x FNPT
Nominal Size1/4 in
Series94MBV
Temperature Rating-40 to 300 deg F
Type2-Piece
Pressure Rating600 psi
Port TypeFull
Softgoods MaterialFluorocarbon
Trim MaterialBrass Stem and TFE Seat
Ball MaterialChrome Plated Brass
Inlet to Outlet Length1.95 in
Manufacturer NameApollo Conbraco
Top to Inlet Center1.09 in
ApplicationDesigned For Water, Oil Or Gas In Commercial And Light Industrial Applications
Warranty2 Years
Standards and ApprovalsANSI Z21.15-2009/CSA 9.1-2009 (1/2 psi) Manually Operated Gas Valves for Appliances,ASME B16.44-2002,MSS-SP-110

Item Features

  • Multiple connection options
  • Rugged forged construction
  • Blow-out proof stem
  • Large raised wrench flats
  • Optimum flow rate
  • 600 psi at 100 deg F maximum
  • Brass plated steel handle nut
  • Zinc plated steel with vinyl handle
  • Brass packing nut
  • Fluorocarbon O-ring
