APOLLOPRESS 77WLF Series Ball Valve

Apollo™ 77WLF-104-01A 89-140 89-140 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Carbon Steel Body, Full Port

CBPN:172717

UPC:670750898914

MPN:77WLF-104-01A

Price:
$57.27 / EA
Prop 65:

DESCRIPTION

Apollo™ Ball Valve, 2-Piece, Series: 89-140, 1/2 in Nominal, FNPT End Style, 2000 psig CWP Pressure, Full Port, Latch Lock Lever Handle Actuator, Stainless Steel Ball, 2.23 in Inlet to Outlet Length, 1.79 in Top to Inlet Center, Carbon Steel Body, 316 Stainless Steel/RPTFE Trim, Graphite/MPTFE/PTFE Softgoods, Domestic

The Lead Free APOLLOXPRESS® 77WLF ball valve is ideal for installation in potable water systems requiring NSF 61 or Lead Free approval. Now with Leak Before Press® feature and 250 psig maximum working pressure.

Apollo™ 77WLF-104-01A 89-140 89-140 2-Piece Ball Valve, 1/2 in Nominal, FNPT End Style, Carbon Steel Body, Full Port

CBPN:172717

MPN:77WLF-104-01A

UPC:670750898914

Price:
$57.27 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ Ball Valve, 2-Piece, Series: 89-140, 1/2 in Nominal, FNPT End Style, 2000 psig CWP Pressure, Full Port, Latch Lock Lever Handle Actuator, Stainless Steel Ball, 2.23 in Inlet to Outlet Length, 1.79 in Top to Inlet Center, Carbon Steel Body, 316 Stainless Steel/RPTFE Trim, Graphite/MPTFE/PTFE Softgoods, Domestic

The Lead Free APOLLOXPRESS® 77WLF ball valve is ideal for installation in potable water systems requiring NSF 61 or Lead Free approval. Now with Leak Before Press® feature and 250 psig maximum working pressure.

Specifications

BrandApollo™
Series89-140
Type2-Piece
Body MaterialCarbon Steel
Domestic/ImportDomestic
End StyleFNPT
Nominal Size1/2 in
Pressure Rating2000 psig CWP
Actuator TypeLatch Lock Lever Handle
Port TypeFull
Softgoods MaterialGraphite/MPTFE/PTFE
Trim Material316 Stainless Steel/RPTFE
Ball MaterialStainless Steel
Inlet to Outlet Length2.23 in
Top to Inlet Center1.79 in
Weight1.09 lbs
IncludesAdjustable Packing Gland
Standards ApprovalsAPI 607,ASTM A216 Body,ASTM A276 Stem/Ball,CSA CGA 3.16-M88,MSS SP-110

Item Features

  • 24 - RPTFE bearing
  • 46 - latch-lock lever lock in closed position only
  • Investment cast components
  • Reinforced seat
  • Mounting pad for easy actuator mounting
  • Blow-out proof stem design
  • Zinc phosphate corrosion protection
  • Cold non-shock body rating
  • 150 psig saturated steam
  • NACE MR0175 (2000) and MR0103 (2003) compliance
  • PTFE seal, graphite packing and MPTFE stem packing
  • Lead-free
