Apollo 77F-100 Series Ball Valve

Apollo™ 77F-140-01 2-Piece Ball Valve, 3 in Nominal, FNPT End Style, Forged Brass Body, Full Port, RPTFE Softgoods, Domestic

CBPN:227477

UPC:670750975073

MPN:77F-140-01

Price:
$419.93 / EA

DESCRIPTION

Apollo™ Ball Valve, 2-Piece, Series: 77F-140, 3 in Nominal, FNPT, 400 psi CWP, 0 to 400 deg F, Full Port, Standard Lever Actuator, Stainless Steel Ball, 7.05 in Inlet to Outlet Length, 5.03 in Top to Inlet Center, Forged Brass Body, Stainless Steel Stem and RPTFE Seat Trim, RPTFE, Domestic

The Apollo™ 77F-100 series is a full port forged brass ball valve suitable for a wide range of flow control applications including HVAC, fuel gas, fire protection, irrigation etc. These NPT threaded, 2-piece valves combine reliable operation with maximum economy. Valves include most pertinent agency approvals. Proudly Made in the USA.

Apollo™ 77F-140-01 2-Piece Ball Valve, 3 in Nominal, FNPT End Style, Forged Brass Body, Full Port, RPTFE Softgoods, Domestic

CBPN:227477

MPN:77F-140-01

UPC:670750975073

Price:
$419.93 / EA

Apollo Valve Logo

DESCRIPTION

Apollo™ Ball Valve, 2-Piece, Series: 77F-140, 3 in Nominal, FNPT, 400 psi CWP, 0 to 400 deg F, Full Port, Standard Lever Actuator, Stainless Steel Ball, 7.05 in Inlet to Outlet Length, 5.03 in Top to Inlet Center, Forged Brass Body, Stainless Steel Stem and RPTFE Seat Trim, RPTFE, Domestic

The Apollo™ 77F-100 series is a full port forged brass ball valve suitable for a wide range of flow control applications including HVAC, fuel gas, fire protection, irrigation etc. These NPT threaded, 2-piece valves combine reliable operation with maximum economy. Valves include most pertinent agency approvals. Proudly Made in the USA.

Specifications

BrandApollo™
Series77F-140
Type2-Piece
Body MaterialForged Brass
Domestic/ImportDomestic
End StyleFNPT
Nominal Size3 in
Pressure Rating400 psi CWP
Temperature Rating0 to 400 deg F
Actuator TypeStandard Lever
Port TypeFull
Softgoods MaterialRPTFE
Trim MaterialStainless Steel Stem and RPTFE Seat
Ball MaterialStainless Steel
Inlet to Outlet Length7.05 in
Top to Inlet Center5.03 in
Weight19.7 lbs

Item Features

  • Heavy pattern forged design
  • Corrosion resistant materials
  • Adjustable stem packing
  • Blow-out proof stem
  • Silicone free assembly
  • 100% factory tested
  • 150 psi working steam pressure
  • Vacuum service to 29 in Hg
  • RPTFE stem packing
