Apollo™ 61YLF-192-01 61YLF Y-Pattern Swing Check Valve, 3/8 in Nominal, NPT End Style, 125 lb, Bronze Body, Domestic
CBPN:177324
UPC:670750686245
MPN:61YLF19201
Price:
$92.96 / EA
Prop 65:
DESCRIPTION
Apollo™, 61YLF19201, Swing Check Valve, Y-Pattern, Series: 161T-LF, 3/8 in Nominal, NPT End Style, 200 psi CWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, Yes Low Lead Compliance, 4.5 gpm Flow Rate, Media: Steam, 2.14 in Inlet to Outlet Length, Bronze Body, Brass/Bronze Trim, 1.51 in H Dimensions, Domestic
The lead free Apollo™ Model 161T-LF (61YLF Series) Swing Check provides a reliable, long lasting, Made in the USA alternative to globally sourced check valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality materials. The Apollo™ swing check may be installed in either horizontal or vertical orientation with upward flow.
Apollo™ 61YLF-192-01 61YLF Y-Pattern Swing Check Valve, 3/8 in Nominal, NPT End Style, 125 lb, Bronze Body, Domestic
CBPN:177324
MPN:61YLF19201
UPC:670750686245
Price:
$92.96 / EA
Prop 65:
DESCRIPTION
Apollo™, 61YLF19201, Swing Check Valve, Y-Pattern, Series: 161T-LF, 3/8 in Nominal, NPT End Style, 200 psi CWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, Yes Low Lead Compliance, 4.5 gpm Flow Rate, Media: Steam, 2.14 in Inlet to Outlet Length, Bronze Body, Brass/Bronze Trim, 1.51 in H Dimensions, Domestic
The lead free Apollo™ Model 161T-LF (61YLF Series) Swing Check provides a reliable, long lasting, Made in the USA alternative to globally sourced check valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality materials. The Apollo™ swing check may be installed in either horizontal or vertical orientation with upward flow.
Specifications
Brand: Apollo™
Weight: 0.62lbs
Body Material: Bronze
End Style: NPT
Flow Rate: 4.5 gpm
Nominal Size: 3/8 in
Series: 161T-LF
Temperature Rating: -20 to 406 deg F
Type: Y-Pattern
Pressure Rating: 200 psi CWP
Dimensions: 1.51 in H
Media: Steam
Pressure Class: 125 lb
Low Lead Compliance: Yes
Trim Material: Brass/Bronze
Inlet to Outlet Length: 2.14 in
Manufacturer Name: Apollo Conbraco
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASME B1.20.1 | ASME B1.20.1 | ASTM B584-C89836 Body | CSA B51 Canadian Registration No. 0C14667 | C27451 Lead-Free Seat | Complies with Federal Public Law 111-380 | ANSI 3rd Party Approved | MSS SP-80 Design and Tested | MSS SP-139 | NSF/ANSI 372 Lead-Free | NSF/AND 61 | PROP65: Cancer and Reproductive Harm
Item Features
- Renewable bronze seat disc
- Dezincification resistant bronze construction
- 100% factory tested per MSS SP-139
- Cast, machined and assembled in the USA
- Brass seat/Bronze seat disc
- Lead free - The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
