Apollo™ APOLLOXPRESS® 61LF10401PR 61LF-PR Standard In-Line Check Valve, 3/4 in Nominal, Press End Style, 3.5 gpm Flow Rate, Lead Free Bronze Body, Domestic
CBPN: 188525
UPC:670750663680
MPN:61LF-104-01PR
Price:
$84.10 / EA
Prop 65:
DESCRIPTION
Apollo™ 61LF10401PR, In-Line Check Valve, Standard, Series: 61LF-PR, 3/4 in Nominal, Press End Style, 250 psi Pressure, 300 psi Pressure Class, 0 to 250 deg F, Yes Low Lead Compliance, 3.5 gpm Flow Rate, Media: Liquid, 5 in Inlet to Outlet Length, Bronze Body, Brass Trim, EPDM O-Ring Softgoods, Domestic
The lead free APOLLOPRESS® Model CVB-PRLF (61LF series) BALL-CONE® check valves with press connections offer reliable protection against reverse flow in potable water applications using proven ASTM quality materials made in the USA. Valves may be installed in both horizontal and vertical flow with upward flow.
Apollo™ APOLLOXPRESS® 61LF10401PR 61LF-PR Standard In-Line Check Valve, 3/4 in Nominal, Press End Style, 3.5 gpm Flow Rate, Lead Free Bronze Body, Domestic
CBPN: 188525
MPN:61LF-104-01PR
UPC:670750663680
Price:
$84.10 / EA
Prop 65:
DESCRIPTION
Apollo™ 61LF10401PR, In-Line Check Valve, Standard, Series: 61LF-PR, 3/4 in Nominal, Press End Style, 250 psi Pressure, 300 psi Pressure Class, 0 to 250 deg F, Yes Low Lead Compliance, 3.5 gpm Flow Rate, Media: Liquid, 5 in Inlet to Outlet Length, Bronze Body, Brass Trim, EPDM O-Ring Softgoods, Domestic
The lead free APOLLOPRESS® Model CVB-PRLF (61LF series) BALL-CONE® check valves with press connections offer reliable protection against reverse flow in potable water applications using proven ASTM quality materials made in the USA. Valves may be installed in both horizontal and vertical flow with upward flow.
Specifications
Brand: Apollo™
Weight: 0.99 lbs
Nominal Size: 3/4 in
End Style: Press
Pressure Class: 300 psi
Low Lead Compliance: Yes
Flow Rate: 3.5 gpm
Body Material: Lead Free Bronze
Inlet to Outlet Length: 5 in
Manufacturer Name: Apollo Conbraco
Media: Liquid
Pressure Rating: 250 psi
Series: 61LF-PR
Softgoods Material: EPDM O-Ring
Temperature Rating: 0 to 250 deg F
Trim Material: Brass
Type: Standard
Application: Reliable Protection Against Reverse Flow In Potable Water Applications
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ARRA Compliant | ASTM B584-C89836 Valve Body | CRN OC 11218.5C | NSF/ANSI 61-8 | NSF/ANSI 372 | UNS C27450 Stem | PROP65: Cancer and Reproductive Harm
Item Features
- Fast, reliable, economical press installation
- Ridgid XL press tool compatible
- Leak before press technology
- 0.5 psi spring cracking pressure is standard
- Tight shut-off with liquid media
- Straight-through flow design efficiency
- RPTFE Ball Cone for chemical resistance
- 0.5 psig cracking pressure
