Apollo™ 36H20003

Apollo™ 36H20003 Pressure Reducing Valve, 3 in, FNPT, 75 to 125 psig, Bronze Body, Domestic

CBPN:247027

UPC:670750968709

MPN:36H20003

Price:
$2480.99 / ea
Availability Information
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
Prop 65:

DESCRIPTION

Apollo™ Pressure Reducing Valve, Series: 36H, 3 in Nominal, FNPT, 75 to 125 psig, 33 to 180 deg F, Media: Water, 10.37 in Inlet to Outlet Length, Bronze Body, EPDM Trim, Nitrile, 19.12 in H, Domestic

Apollo™ PRH (36H Series) Pressure Reducing Valves are designed for commercial, industrial, and institutional applications to reduce incoming water pressure for protection of plumbing system components and to reduce water consumption. The valves are made with proven ASTM grade bronze and stainless steel materials. The PRH provides high capacity flow with low pressure drop. It is designed with an integral by-pass relief to protect against thermal expansion downstream. The bottom access enables easy in-line cleaning or seat replacement.

Apollo™ 36H20003 Pressure Reducing Valve, 3 in, FNPT, 75 to 125 psig, Bronze Body, Domestic

CBPN:247027

MPN:36H20003

UPC:670750968709

Price:
$2480.99 / ea
Availability Information
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ Pressure Reducing Valve, Series: 36H, 3 in Nominal, FNPT, 75 to 125 psig, 33 to 180 deg F, Media: Water, 10.37 in Inlet to Outlet Length, Bronze Body, EPDM Trim, Nitrile, 19.12 in H, Domestic

Apollo™ PRH (36H Series) Pressure Reducing Valves are designed for commercial, industrial, and institutional applications to reduce incoming water pressure for protection of plumbing system components and to reduce water consumption. The valves are made with proven ASTM grade bronze and stainless steel materials. The PRH provides high capacity flow with low pressure drop. It is designed with an integral by-pass relief to protect against thermal expansion downstream. The bottom access enables easy in-line cleaning or seat replacement.

Specifications

BrandApollo™
Body MaterialBronze
Domestic/ImportDomestic
End StyleFNPT
Nominal Size3 in
Pressure Range75 to 125 psig
Series36H
Temperature Rating33 to 180 deg F
Dimensions19.12 in H
MediaWater
Softgoods MaterialNitrile
Trim MaterialEPDM
Inlet to Outlet Length10.37 in

Item Features

  • Sealed spring cage for vault installations
  • Ultra-high flow capacity
  • Internal thermal expansion by-pass
  • Stainless steel bolts and spring
  • Nitrile O-ring
  • EPDM seat disc
  • Standard
