Apollo™ 36ELF11403T

Apollo™ 36ELF11403T Pressure Reducing Valve, 3/4 in Nominal, Single Union x FNPT End Style, 75 to 150 psig Pressure, Bronze Body, Domestic

CBPN:250561

UPC:670750679247

MPN:36ELF11403T

Price:
$88.36 / EA
Prop 65:

DESCRIPTION

Apollo™ Pressure Reducing Valve, Series: 36ELF, 3/4 in Nominal, Single Union x FNPT End Style, 75 to 150 psig Pressure, 33 to 180 deg F, Media: Water, 5.49 in Inlet to Outlet Length, Bronze Body, EPDM Trim, EPDM Softgoods, 2-3/4 in D x 6 in H Dimensions, Domestic

The Apollo™ 36ELF series lead free Pressure Reducing Valve is designed to conserve water and protect water distribution systems by automatically reducing elevated supply pressures. The dezincification resistant bronze body, stainless steel adjusting screw and dielectric polymer cage provide maximum corrosion resistance. Designed for easy in-line servicing with simple cartridge removal.

Apollo™ 36ELF11403T Pressure Reducing Valve, 3/4 in Nominal, Single Union x FNPT End Style, 75 to 150 psig Pressure, Bronze Body, Domestic

CBPN:250561

MPN:36ELF11403T

UPC:670750679247

Price:
$88.36 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ Pressure Reducing Valve, Series: 36ELF, 3/4 in Nominal, Single Union x FNPT End Style, 75 to 150 psig Pressure, 33 to 180 deg F, Media: Water, 5.49 in Inlet to Outlet Length, Bronze Body, EPDM Trim, EPDM Softgoods, 2-3/4 in D x 6 in H Dimensions, Domestic

The Apollo™ 36ELF series lead free Pressure Reducing Valve is designed to conserve water and protect water distribution systems by automatically reducing elevated supply pressures. The dezincification resistant bronze body, stainless steel adjusting screw and dielectric polymer cage provide maximum corrosion resistance. Designed for easy in-line servicing with simple cartridge removal.

Specifications

BrandApollo™
Series36ELF
Body MaterialBronze
Domestic/ImportDomestic
End StyleSingle Union x FNPT
Nominal Size3/4 in
Pressure Range75 to 150 psig
Temperature Rating33 to 180 deg F
Dimensions2-3/4 in D x 6 in H
MediaWater
Softgoods MaterialEPDM
Trim MaterialEPDM
Inlet to Outlet Length5.49 in
Weight2.4 lbs
Standards ApprovalsARRA Compliant,ASSE 1003,cCSAus Certified,CSA Certified File No. B356,Federal Public Law 111-380,IAPMO/UPC Listed,NSF/ANSI 372 Lead-Free,NSF/ANSI/CAN 61 Water Quality

Item Features

  • Lead free direct acting cartridge style regulator designed for maximum economy and efficiency
  • Balanced piston design
  • Stainless steel adjusting screw and nut
  • Sealed cage for vault installations
  • Built-in thermal expansion bypass
  • Large area integral stainless steel strainer
  • Modular seat disc and strainer cartridge
  • High flow and high efficiency design
  • Factory tested and preset at 60 psi
  • Without gauge
