Apollo™ 3610803 36 Direct Acting Pressure Reducing Valve, 2 in Nominal, FNPT Union x FNPT End Style, 75 to 125 psi Pressure, Bronze Body, Domestic
CBPN: 126486
UPC:670750563249
MPN:3610803
Price:
$1583.64 / EA
Prop 65:
DESCRIPTION
Apollo™ 3610803, Pressure Reducing Valve, Direct Acting, Series: 36, 2 in Nominal, Single Union NPT End Style, 75 to 125 psi Pressure, 33 to 180 deg F, Media: Water, 9-7/8 in Inlet to Outlet Length, Bronze Body, EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring Softgoods, 11-1/2 in H x 5-3/4 in D Dimensions, Domestic
Apollo™ Model PR (36 Series) Pressure Reducing Valves are designed to protect residential and commercial water distribution systems by controlling excessive pressures. The valves are built for long reliable service with proven ASTM grade materials including a bronze body and stainless steel strainer.
Apollo™ 3610803 36 Direct Acting Pressure Reducing Valve, 2 in Nominal, FNPT Union x FNPT End Style, 75 to 125 psi Pressure, Bronze Body, Domestic
CBPN: 126486
MPN:3610803
UPC:670750563249
Price:
$1583.64 / EA
Prop 65:
DESCRIPTION
Apollo™ 3610803, Pressure Reducing Valve, Direct Acting, Series: 36, 2 in Nominal, Single Union NPT End Style, 75 to 125 psi Pressure, 33 to 180 deg F, Media: Water, 9-7/8 in Inlet to Outlet Length, Bronze Body, EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring Softgoods, 11-1/2 in H x 5-3/4 in D Dimensions, Domestic
Apollo™ Model PR (36 Series) Pressure Reducing Valves are designed to protect residential and commercial water distribution systems by controlling excessive pressures. The valves are built for long reliable service with proven ASTM grade materials including a bronze body and stainless steel strainer.
Specifications
Brand: Apollo™
Weight: 22.5 lbs
Nominal Size: 2 in
End Style: FNPT Union x FNPT
Pressure Range: 75 to 125 psi
Body Material: Bronze
Dimensions: 11-1/2 in H x 5-3/4 in D
Inlet to Outlet Length: 9-7/8 in
Manufacturer Name: Apollo Conbraco
Media: Water
Series: 36
Softgoods Material: EPDM Seat Disc/Polypropylene Seal/Nitrile O-Ring
Temperature Rating: 33 to 180 deg F
Trim Material: EPDM/Brass
Type: Direct Acting
Application: Residential and Commercial Applications
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASSE 1003 | CSA B356 | ASTM B16 Stem | ASTM B584 Body | FDA Approved Seat Disc/O-Ring | UPC Listed | PROP65: Cancer and Reproductive Harm
Item Features
- 100% factory tested, preset to 50 psi
- Integral stainless steel strainer
- Balanced piston design
- Internal thermal expansion by-pass
- Nitrile O-ring
- EPDM seat disc/brass stem
- No guage
- No option
