Apollo™ 30LF00901

Apollo™ 30LF00901 101T-LF Rising Stem Gate Valve, 2-1/2 in Nominal, FNPT End Style, 125 lb, Lead Free Bronze Body, Handwheel Actuator, Domestic

CBPN: 208639

UPC:670750687099

MPN:30LF00901

Price:
$1013.71 / EA
Prop 65:

DESCRIPTION

Apollo™ Gate Valve, Rising Stem, Series: 101T-LF, 2-1/2 in Nominal, FNPT End Style, 200 psi CWP/125 psi SWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, 395 gpm Flow Rate, Full Port, Media: Water, Handwheel Actuator, 14.58 in Open Top to Inlet Center, Bronze Body, Brass/Bronze Trim, Grafoil® Softgoods, 4.13 in L Dimensions, Domestic

The lead free Apollo™ Model 101T-LF (30LF Series) Gate valve provides a Made in the USA alternative to globally sourced multi-turn valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality lead free materials.

Apollo™ 30LF00901 101T-LF Rising Stem Gate Valve, 2-1/2 in Nominal, FNPT End Style, 125 lb, Lead Free Bronze Body, Handwheel Actuator, Domestic

CBPN: 208639

MPN:30LF00901

UPC:670750687099

Price:
$1013.71 / EA

Prop 65:
Apollo Valve Logo

DESCRIPTION

Apollo™ Gate Valve, Rising Stem, Series: 101T-LF, 2-1/2 in Nominal, FNPT End Style, 200 psi CWP/125 psi SWP Pressure, 125 lb Pressure Class, -20 to 406 deg F, 395 gpm Flow Rate, Full Port, Media: Water, Handwheel Actuator, 14.58 in Open Top to Inlet Center, Bronze Body, Brass/Bronze Trim, Grafoil® Softgoods, 4.13 in L Dimensions, Domestic

The lead free Apollo™ Model 101T-LF (30LF Series) Gate valve provides a Made in the USA alternative to globally sourced multi-turn valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality lead free materials.

Specifications

BrandApollo™
Weight13.47 lbs
Nominal Size2-1/2 in
End StyleFNPT
Pressure Class125 lb
Body MaterialLead Free Bronze
Softgoods MaterialGrafoil
Actuator TypeHandwheel
Dimensions4.13 in L
Flow Rate395 gpm
Manufacturer NameApollo Conbraco
MediaWater
Port TypeFull
Pressure Rating200 psi CWP
Series101T-LF
Temperature Rating-20 to 406 deg F
Top to Inlet Center14.58 in Open
Trim MaterialBrass/Bronze
TypeRising Stem
ApplicationPotable Water Service
Warranty5 Years
Domestic/ImportDomestic
Country of OriginUS
Standards and ApprovalsARRA Compliant | ASME B1.20.1 | ASTM B584-C89836 Body/Disc Wedge | CSA B51 CRN 0C14667.5 | Federal Public Law 111-380 | MSS SP-80/139 | NSF/ANSI 61/372 | PROP65: Cancer and Reproductive Harm

Item Features

  • Guided solid bronze disc wedge
  • Screw-in bonnet
  • Rugged malleable iron hand wheel
  • Back seat protection
  • 100% factory tested
  • The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
  • Brass stem/bronze disc wedge
